Johnson Controls 3G-OTH-67926 — Technical Specifications
The JOHNSON CONTROLS M9220-GGC-3 is a proportional, spring-return fail-safe damper actuator with 177 in-lb torque, 24V AC/DC input, and a 90° stroke with CW/CCW shaft rotation. It features a self-centering clamping shaft, hardwired electrical connection, and an included auxiliary switch. This NEMA 2 / IP54 rated actuator is compatible with building automation systems.
Technical Specifications
| Parameter | Value |
|---|---|
| Brand | JOHNSON CONTROLS |
| Shaft Type | Self-Centering Clamping |
| Input Voltage | 24V AC/DC |
| Stroke Degree | 90° |
| Shaft Rotation | CW/CCW |
| Manufacturer Part Number | M9220-GGC-3 |
| Auxiliary Switch Included | Yes |
| Electrical Connection Type | Hardwired |
| For Use With Building Automation Systems | Building Automation System Compatible |
