GUARDIAN FLOOR PROTECTION

Guardian Floor Protection is a manufacturer of cable management and floor protection products, including cable ramps, cable protectors, and hose bridges. The brand's product line is designed to protect cables, hoses, and cords from damage in areas with foot or vehicle traffic, while also reducing tripping hazards. Guardian Floor Protection products are commonly used in industrial, commercial, and event settings where temporary or permanent cable routing is required. The range includes both hinged-cover and drop-over styles, with channel counts from one to five, accommodating cable diameters from 1/2 inch up to 3 1/4 inches. Materials include rubber, polyurethane, and polyethylene, with color options such as black, yellow, and black/yellow for high visibility. Load capacities vary by model, with some ramps rated for vehicles up to 20,000 pounds per axle. 3G Electric supplies Guardian Floor Protection cable ramps and floor protection products globally. The product line includes straight sections and modular components that can be connected to form continuous runs. Hinged-cover ramps allow cables to be laid in place and then covered, while drop-over ramps are placed over existing cables. Connection styles include T-shaped and L-shaped, enabling configuration flexibility. These products are used in manufacturing plants, warehouses, data centers, and public events to manage cables safely. 3G Electric provides access to the full range of Guardian Floor Protection products, with logistics support for international shipping. Technical specifications, including dimensions, channel counts, and load ratings, are available to assist with selection. 3G Electric can source specific models and provide quotes based on project requirements.

Genuine
OEM Parts
Expert
Tech Support
1 Day
Quote Response
Worldwide
Origin
EXW Singapore
Collect or forward from our office
Datasheets on Request
Technical specs & drawings
1-Day Quote Response
Singapore-based team
Browse:
Show
Page 1 of 1

About GUARDIAN FLOOR PROTECTION

Guardian Floor Protection is a manufacturer of cable management and floor protection products, including cable ramps, cable protectors, and hose bridges. The brand's product line is designed to protect cables, hoses, and cords from damage in areas with foot or vehicle traffic, while also reducing tripping hazards. Guardian Floor Protection products are commonly used in industrial, commercial, and event settings where temporary or permanent cable routing is required. The range includes both hinged-cover and drop-over styles, with channel counts from one to five, accommodating cable diameters from 1/2 inch up to 3 1/4 inches. Materials include rubber, polyurethane, and polyethylene, with color options such as black, yellow, and black/yellow for high visibility. Load capacities vary by model, with some ramps rated for vehicles up to 20,000 pounds per axle. 3G Electric supplies Guardian Floor Protection cable ramps and floor protection products globally. The product line includes straight sections and modular components that can be connected to form continuous runs. Hinged-cover ramps allow cables to be laid in place and then covered, while drop-over ramps are placed over existing cables. Connection styles include T-shaped and L-shaped, enabling configuration flexibility. These products are used in manufacturing plants, warehouses, data centers, and public events to manage cables safely. 3G Electric provides access to the full range of Guardian Floor Protection products, with logistics support for international shipping. Technical specifications, including dimensions, channel counts, and load ratings, are available to assist with selection. 3G Electric can source specific models and provide quotes based on project requirements.

Common Applications

  • Manufacturing plants — 5-channel hinged-cover cable ramp (SKU 61HY48) for routing multiple cables and hoses across forklift traffic areas.
  • Warehouse aisles — 3-channel drop-over cable ramp (SKU 61HY54) to protect cables from pallet jacks and carts.
  • Data centers — 2-channel hinged-cover cable ramp (SKU 61HY51) for organizing and protecting power and network cables.
  • Event venues — 1-channel drop-over cable ramp (SKU 61HY52) for temporary cable runs across walkways.
  • Loading docks — 2-channel drop-over cable ramp (SKU 61HY53) to shield hoses and cables from truck traffic.
  • Industrial facilities — 3-channel hinged-cover cable ramp (SKU 61HY50) for high-traffic areas with cables up to 2 1/2 inches.

Frequently asked questions

Common questions about GUARDIAN FLOOR PROTECTION from 3G Electric.

What is the maximum cable diameter for Guardian Floor Protection 2-channel hinged-cover cable ramps?

The Guardian Floor Protection 2-channel hinged-cover cable ramp (SKU 61HY51, MPN DH-CP-7) accommodates cables up to 3 1/4 inches in diameter. It is constructed of rubber in a black/yellow color and measures 24 inches in width. This model is a straight section with a hinged cover, allowing cables to be placed and then covered. For applications requiring smaller diameters, other models in the line offer different capacities.

What materials are used in Guardian Floor Protection cable ramps?

Guardian Floor Protection cable ramps are available in rubber, polyurethane, and polyethylene. For example, the 5-channel hinged-cover ramp (SKU 61HY48) is made of polyurethane, while the 3-channel drop-over ramp (SKU 61HY54) is made of rubber. The 1-channel drop-over ramp (SKU 61HY52) uses polyethylene. Material selection affects weight, durability, and chemical resistance. Rubber offers good traction and impact resistance, polyurethane provides high load capacity, and polyethylene is lightweight.

How many channels are available in Guardian Floor Protection cable protectors?

Guardian Floor Protection cable protectors are available with 1, 2, 3, or 5 channels. The 1-channel drop-over ramp (SKU 61HY52) handles cables up to 1/2 inch. The 2-channel hinged-cover ramp (SKU 61HY51) handles up to 3 1/4 inches. The 3-channel hinged-cover ramp (SKU 61HY50) handles up to 2 1/2 inches. The 5-channel hinged-cover ramps (SKUs 61HY48 and 61HY49) handle up to 1 1/4 inches and 1 1/2 inches, respectively. Channel count and diameter capacity vary by model.

What is the difference between hinged-cover and drop-over cable ramps from Guardian Floor Protection?

Hinged-cover cable ramps have a lid that opens to allow cables to be placed inside the channel, then closed for protection. Drop-over cable ramps are placed over existing cables without a hinged lid. Hinged-cover models, such as SKU 61HY51, are typically used for permanent or semi-permanent installations where cables are added or removed. Drop-over models, such as SKU 61HY53, are suited for temporary setups where cables are already in place. Both types protect cables from traffic and reduce tripping hazards.

What are the load capacities of Guardian Floor Protection cable ramps?

Load capacities vary by model. The 3-channel drop-over cable ramp (SKU 61HY54) has a load capacity of 20,000 pounds per axle. Other models have different ratings based on material and design. For specific load capacity requirements, consult the individual product specifications. These ramps are designed to withstand vehicle traffic in industrial and commercial settings. Always verify that the selected ramp meets the load requirements of the intended application.

Can Guardian Floor Protection cable ramps be connected to form longer runs?

Yes, many Guardian Floor Protection cable ramps feature connection styles that allow multiple sections to be joined. For example, the 1-channel drop-over ramp (SKU 61HY52) has an L-shaped connection, while the 2-channel drop-over ramp (SKU 61HY53) has a T-shaped connection. These connections enable continuous runs of cable protection. The modular design allows for flexibility in configuring the length and shape of the cable ramp system to suit the installation site.
