PINNACLE

PINNACLE is a brand of industrial weighing equipment, primarily floor scales and related material handling accessories. The product line is designed for heavy-duty applications where accurate, repeatable weight measurement is required for palletized goods, drums, and other bulk loads. 3G Electric supplies PINNACLE floor scales, ramps, and anchor plates to industrial buyers worldwide, supporting applications in receiving, shipping, production, and inventory control.

Genuine
OEM Parts
Expert
Tech Support
1 Day
Quote Response
Worldwide
Origin
EXW Singapore
Collect or forward from our office
Datasheets on Request
Technical specs & drawings
1-Day Quote Response
Singapore-based team
Browse:
Show
Page 1 of 2
← Prev12Next →

About PINNACLE

PINNACLE is a brand of industrial weighing equipment, primarily floor scales and related material handling accessories. The product line is designed for heavy-duty applications where accurate, repeatable weight measurement is required for palletized goods, drums, and other bulk loads. 3G Electric supplies PINNACLE floor scales, ramps, and anchor plates to industrial buyers worldwide, supporting applications in receiving, shipping, production, and inventory control.

The core of the PINNACLE range consists of steel-platform floor scales with capacities from 5,000 lb to 10,000 lb. Readability options include 1 lb (0.5 kg) and 2 lb (1 kg), depending on the model. Platforms are available in sizes such as 48 in x 48 in and 60 in x 60 in, with some models supplied without an indicator for integration into existing weighing systems. Models with indicators feature LED displays and RS-232 connection ports for data output to printers, computers, or other peripheral devices. Weighing units can be configured for pounds or kilograms, and the scales are constructed with steel platforms to withstand repeated loading and unloading in industrial environments.

Complementing the scales, PINNACLE offers floor scale ramps in carbon steel with 4-inch overall height and widths of 48 inches or 59 inches. These ramps provide a transition for pallet jacks, forklifts, and other material handling equipment to access the scale platform. The ramps are rated to 10,000 lb, matching the higher-capacity scale models. Floor anchor plates are also available to secure scales to the floor, reducing movement during loading and unloading. These accessories are designed to work with specific scale models, such as the PS3000-55-5N and similar part numbers.

The PINNACLE product family is characterized by practical, application-focused design. The scales use steel platforms, which are common in industrial weighing for their durability and resistance to impact. The RS-232 port allows for integration with data collection systems, which is useful for recording weight transactions in shipping and receiving departments. The availability of models without indicators gives buyers the option to use their own indicators or connect to existing control systems. The ramps and anchor plates address the need for safe and stable access to the scale, which is a common requirement in facilities using pallet jacks and forklifts.

3G Electric supports the PINNACLE line by stocking multiple SKUs and providing logistics support for global delivery. Buyers can request quotes for specific models, and 3G Electric can assist with identifying the appropriate scale, ramp, or accessory based on capacity, platform size, readability, and connectivity requirements. The product range is suitable for industries such as manufacturing, warehousing, logistics, and food processing, where floor scales are used for weighing incoming raw materials, outgoing shipments, and intermediate goods. The accessories ensure that the scales can be installed and used safely in busy industrial settings.

Common Applications

  • Warehousing and logistics — PINNACLE PS3000-44-10N floor scale for weighing incoming and outgoing palletized shipments up to 10,000 lb.
  • Manufacturing — PINNACLE PS3000-55-5N floor scale with RS-232 for recording weight data of raw materials and finished goods.
  • Food processing — PINNACLE PS7055-5N floor platform without indicator for integration into existing washdown or data collection systems.
  • Material handling — PINNACLE 101012-55R ramp for safe forklift and pallet jack access to floor scales in receiving areas.
  • Inventory control — PINNACLE PS7044-5N floor platform for weighing drums and bulk containers in storage areas.
  • Shipping and receiving — PINNACLE 101013 anchor plates to secure floor scales and prevent movement during loading and unloading.

Frequently asked questions

Common questions about PINNACLE from 3G Electric.

What capacities and readabilities are available in PINNACLE floor scales?

PINNACLE floor scales are available with capacities of 5,000 lb and 10,000 lb. Readability options include 1 lb (0.5 kg) for 5,000 lb models and 2 lb (1 kg) for 10,000 lb models. For example, the PS3000-44-10N has a 10,000 lb capacity with 2 lb/1 kg readability, while the PS3000-55-5N has a 5,000 lb capacity with 1 lb/0.5 kg readability. Some models are supplied without an indicator, such as the PS7055-5N, which has a 5,000 lb capacity and 1 lb readability. The weighing units can be set to pounds or kilograms depending on the model.

Do PINNACLE floor scales come with data output capabilities?

Yes, several PINNACLE floor scale models with indicators include an RS-232 connection port. This allows the scale to transmit weight data to external devices such as computers, printers, or remote displays. Models like the PS3000-44-10N and PS3000-55-5N feature RS-232 ports. For scales supplied without an indicator, data output would depend on the indicator used. The RS-232 interface is commonly used for recording weight transactions in shipping, receiving, and inventory management systems.

What are the dimensions and load ratings of PINNACLE floor scale ramps?

PINNACLE floor scale ramps are constructed from carbon steel and have an overall height of 4 inches. They are available in widths of 48 inches and 59 inches. Both ramp models are rated to a 10,000 lb capacity. The ramps are designed to provide a transition for pallet jacks, forklifts, and other material handling equipment to access the scale platform. The 48-inch wide ramp (MPN 101011-44R) and the 59-inch wide ramp (MPN 101012-55R) are intended for use with compatible PINNACLE floor scales.

Can PINNACLE floor scales be used with existing indicators or control systems?

Yes, PINNACLE offers floor platforms without indicators, such as the PS7055-5N (60 in x 60 in, 5,000 lb capacity) and PS7044-5N (48 in x 48 in, 5,000 lb capacity). These platforms can be connected to a separate indicator or integrated into an existing weighing system. This option is useful when a facility already has indicators or wants to use a specific indicator model. The platforms have steel construction and are available with different readabilities and weighing units. Compatibility with third-party indicators depends on the load cell output and connector type, which should be verified with the supplier.

What accessories are available for PINNACLE floor scales?

PINNACLE offers floor scale ramps and floor anchor plates. The ramps are available in 48-inch and 59-inch widths, both with a 4-inch height and 10,000 lb capacity, made from carbon steel. The floor anchor plates (MPN 101013) are used to secure floor scales to the floor and come in a pack of two. They measure 6 inches in overall width and 1/4 inch in overall height. These accessories help with safe access and stable installation of the scales in industrial environments.

What platform sizes are available for PINNACLE floor scales?

PINNACLE floor scales are available in platform sizes including 48 in x 48 in and 60 in x 60 in. For example, the PS7044-5N has a 48 in x 48 in platform, while the PS7055-5N has a 60 in x 60 in platform. Other models in the PS3000 series may have different dimensions. The platform size should be selected based on the size of the loads to be weighed and the available floor space. Larger platforms accommodate bigger pallets or multiple items, while smaller platforms fit in tighter areas.
