VULCAN

VULCAN is a brand of industrial electric heating equipment. The product line includes immersion heaters, cartridge heaters, finned strip heaters, and process thermostats. These components are used in applications requiring direct or indirect heating of liquids, gases, and solid surfaces across manufacturing, chemical processing, food and beverage production, and other industrial settings. VULCAN heaters are available in various sheath materials, watt densities, voltage and phase configurations, and mounting styles to suit different operating conditions. 3G Electric supplies the VULCAN line globally, offering technical buyers access to specification data, product selection support, and quotation services. The product range covers suspended immersion heaters for open tanks, finned strip heaters for forced convection, and other heater types. Suspended immersion heaters are designed for over-the-side mounting in open tanks or vessels. They are available with steel or Incoloy sheaths, which provide varying levels of corrosion resistance. Watt densities range from 20 to 40 W/sq in, with power ratings from 3,000 W to 12,000 W and voltages of 240 V AC in single-phase or three-phase configurations. Overall lengths vary, with examples including 13 in, 17 in, and 20 in. These heaters are suitable for heating water, oils, and chemical solutions. Finned strip heaters are used for forced convection heating. A representative model operates at 120 V AC, single-phase, with a watt density of 32 W/sq in and an overall length of 17 7/8 in. It features offset terminals and is UL recognized. The finned design increases surface area for efficient heat transfer to moving air. Cartridge heaters and process thermostats are also part of the VULCAN offering, though specific models are not detailed in the current sample. Cartridge heaters are typically used for localized heating in metal blocks, molds, and platens. Process thermostats provide temperature control for heating systems. 3G Electric maintains a catalog of VULCAN products with detailed specifications, including voltage, wattage, phase, watt density, sheath material, dimensions, and standards. This allows plant engineers and maintenance managers to compare options and select components that match their requirements. 3G Electric supports the VULCAN line by providing global sourcing, technical documentation, and responsive quotation services. The company serves a worldwide customer base, shipping to various regions without geographic restrictions. For procurement specialists, 3G Electric offers a centralized point of access to VULCAN heating products, streamlining the purchasing process. The product data includes MPNs and SKUs for easy cross-referencing. Overall, VULCAN represents a range of electric heating solutions engineered for industrial use, and 3G Electric facilitates their availability to a global market.

Genuine
OEM Parts
Expert
Tech Support
1 Day
Quote Response
Worldwide
Origin
EXW Singapore
Collect or forward from our office
Datasheets on Request
Technical specs & drawings
1-Day Quote Response
Singapore-based team
Browse:
Show
Page 1 of 21
← Prev123…21Next →

About VULCAN

VULCAN is a brand of industrial electric heating equipment. The product line includes immersion heaters, cartridge heaters, finned strip heaters, and process thermostats. These components are used in applications requiring direct or indirect heating of liquids, gases, and solid surfaces across manufacturing, chemical processing, food and beverage production, and other industrial settings. VULCAN heaters are available in various sheath materials, watt densities, voltage and phase configurations, and mounting styles to suit different operating conditions. 3G Electric supplies the VULCAN line globally, offering technical buyers access to specification data, product selection support, and quotation services. The product range covers suspended immersion heaters for open tanks, finned strip heaters for forced convection, and other heater types. Suspended immersion heaters are designed for over-the-side mounting in open tanks or vessels. They are available with steel or Incoloy sheaths, which provide varying levels of corrosion resistance. Watt densities range from 20 to 40 W/sq in, with power ratings from 3,000 W to 12,000 W and voltages of 240 V AC in single-phase or three-phase configurations. Overall lengths vary, with examples including 13 in, 17 in, and 20 in. These heaters are suitable for heating water, oils, and chemical solutions. Finned strip heaters are used for forced convection heating. A representative model operates at 120 V AC, single-phase, with a watt density of 32 W/sq in and an overall length of 17 7/8 in. It features offset terminals and is UL recognized. The finned design increases surface area for efficient heat transfer to moving air. Cartridge heaters and process thermostats are also part of the VULCAN offering, though specific models are not detailed in the current sample. Cartridge heaters are typically used for localized heating in metal blocks, molds, and platens. Process thermostats provide temperature control for heating systems. 3G Electric maintains a catalog of VULCAN products with detailed specifications, including voltage, wattage, phase, watt density, sheath material, dimensions, and standards. This allows plant engineers and maintenance managers to compare options and select components that match their requirements. 3G Electric supports the VULCAN line by providing global sourcing, technical documentation, and responsive quotation services. The company serves a worldwide customer base, shipping to various regions without geographic restrictions. For procurement specialists, 3G Electric offers a centralized point of access to VULCAN heating products, streamlining the purchasing process. The product data includes MPNs and SKUs for easy cross-referencing. Overall, VULCAN represents a range of electric heating solutions engineered for industrial use, and 3G Electric facilitates their availability to a global market.

Common Applications

  • Chemical processing — VULCAN suspended immersion heaters with Incoloy sheaths (e.g., TI-312TB) for heating corrosive solutions in open tanks.
  • Food and beverage — VULCAN over-the-side immersion heaters with steel sheaths (e.g., TSB-36TB) for heating water and oils in processing vessels.
  • Metal finishing — VULCAN immersion heaters (e.g., TIB-39TB) for maintaining temperature in plating and cleaning baths.
  • HVAC and drying — VULCAN finned strip heaters (e.g., OSF1517-1550A) for forced convection heating in duct systems.
  • Pharmaceutical manufacturing — VULCAN immersion heaters with Incoloy sheaths for heating purified water and chemical intermediates.
  • Plastics and rubber — VULCAN cartridge heaters for localized heating in molds and platens (specific models available upon request).

Guides & Resources

Frequently asked questions

Common questions about VULCAN from 3G Electric.

What sheath materials are available for VULCAN suspended immersion heaters?

VULCAN suspended immersion heaters are offered with steel or Incoloy sheaths. Steel sheaths are suitable for heating water and oils in less corrosive environments. Incoloy sheaths provide higher resistance to corrosion and oxidation, making them appropriate for heating chemical solutions and other aggressive fluids. The choice of sheath material depends on the specific liquid being heated and the operating temperature. For example, models with Incoloy sheaths include the TI-33TB, TI-39TB, and TI-312TB, while steel-sheathed options include the TSB-36TB and 3G-OTH-65957. When selecting a heater, consider the chemical compatibility of the sheath with the process fluid to ensure adequate service life.

What is the watt density of VULCAN finned strip heaters?

VULCAN finned strip heaters are available with watt densities such as 32 W/sq in. For instance, the OSF1517-1550A model operates at 120 V AC, single-phase, with a watt density of 32 W/sq in and an overall length of 17 7/8 inches. Watt density influences the surface temperature of the heater and its suitability for different airflow conditions. Higher watt densities can transfer more heat but may require higher airflow to prevent overheating. The finned design increases the surface area, allowing for efficient heat transfer to forced air. This type of heater is commonly used in duct heating, drying, and other forced convection applications. When selecting a finned strip heater, match the watt density to the airflow and temperature rise requirements of the process.

Can VULCAN immersion heaters be used in three-phase power systems?

Yes, several VULCAN suspended immersion heaters are designed for three-phase operation. Examples include the TI-312TB (12,000 W, 240 V AC, 3-phase) and the TI-39TB (9,000 W, 240 V AC, 3-phase). Three-phase heaters distribute the load across multiple elements, which can be beneficial for higher power ratings and balanced electrical systems. They are typically used in industrial settings where three-phase power is available. When installing a three-phase immersion heater, ensure the power supply matches the voltage and phase configuration of the heater. Consult the product specifications for wiring details and consult a qualified electrician for installation.

What are the typical applications for VULCAN over-the-side immersion heaters?

VULCAN over-the-side immersion heaters are used for heating liquids in open tanks or vessels. Common applications include heating water, oils, and chemical solutions in industrial processes. They are often found in metal finishing, plating, cleaning, and food processing operations. The over-the-side mounting allows the heater to be suspended in the tank without requiring a side-wall opening, simplifying installation and maintenance. These heaters are available in various wattages, voltages, and sheath materials to suit different fluids and temperatures. For example, the TIB-39TB is a 9,000 W, 240 V AC, 3-phase heater with an Incoloy sheath, suitable for corrosive solutions. The TSB-36TB is a 6,000 W, 240 V AC, single-phase heater with a steel sheath, appropriate for water and oils.

What standards do VULCAN heaters comply with?

VULCAN finned strip heaters may carry UL recognition. For example, the OSF1517-1550A model is UL recognized. Other VULCAN heaters may also meet relevant industry standards, but specific certifications should be verified per model. When selecting a heater for a particular application, review the product datasheet for compliance information. UL recognition indicates that the component has been evaluated to applicable safety standards. However, the final installation must also comply with local electrical codes and regulations. 3G Electric provides product documentation that includes available standards information to assist with compliance assessments.

Does 3G Electric supply VULCAN products?

Yes — 3G Electric (S) Pte. Ltd. supplies VULCAN products. We stock the VULCAN catalog and supply genuine factory-original products with full manufacturer warranty and technical support.
