DAYTON AC

DAYTON AC hollow shaft right angle gearmotors are three-phase, TEFC units with input power of 0.25 hp. Output speeds range from 28 RPM to 330 RPM, and maximum torque ratings range from 30 in-lb to 130 in-lb. They feature a hollow shaft for direct mounting on driven shafts and a right-angle configuration for space-saving installation. Common applications include conveyors, packaging machinery, and material handling systems. The TEFC enclosure provides protection against dust and moisture. These gearmotors are available in various gear ratios to match specific speed and torque requirements. For exact dimensions and mounting details, refer to the individual product specifications.

The DAYTON AC 6VEP2 and 6VEP6 are both hollow shaft right angle gearmotors with 0.25 hp three-phase TEFC input. The 6VEP2 delivers 330 RPM output with 30 in-lb maximum torque, while the 6VEP6 delivers 55 RPM output with 130 in-lb maximum torque. The difference lies in the gear ratio: the 6VEP2 is a higher-speed, lower-torque unit, and the 6VEP6 is a lower-speed, higher-torque unit. Both are designed for direct mounting on driven shafts. Selection depends on the required output speed and torque for the application. Other models in the series offer intermediate speeds and torque ratings.

DAYTON AC gearmotors with TEFC enclosures are designed to protect against dust and moisture but are not specifically rated for washdown environments. TEFC enclosures provide a degree of protection against water spray, but they are not intended for high-pressure cleaning or immersion. For washdown applications, additional protection or a different enclosure type may be required. It is important to verify the IP rating of the specific model if washdown exposure is expected. The standard TEFC enclosure is suitable for many industrial environments where dust and occasional moisture are present, but not for direct hose-down. Consult the product datasheet for specific environmental ratings.

3G Electric supplies DAYTON AC replacement motors and adapters, such as the 24UV03 AC motor and adapter assembly. This assembly provides mechanical coupling and AC power conversion for continuous-duty applications like conveyors, pumps, and fans. The adapter allows the motor to interface with existing equipment, facilitating maintenance and retrofit. The replacement motor is designed to match the original specifications for fit and function. When ordering, verify the manufacturer part number and compatibility with your equipment. 3G Electric can assist in identifying the correct replacement components based on the original motor's specifications and application requirements.

To select a DAYTON AC gearmotor for a conveyor, determine the required output speed and torque. The gearmotor's output speed should match the desired conveyor speed, and its torque rating must exceed the maximum load torque. Consider the mounting configuration: hollow shaft right angle gearmotors allow direct mounting on the driven shaft, which can simplify installation. Check the input power available; these units are 0.25 hp three-phase. Also consider the environment: TEFC enclosures are suitable for dusty or moist conditions but not washdown. Review the available models, such as 6VEP2 through 6VEP8, which offer various speed and torque combinations. For assistance, contact 3G Electric with your application details.

The maximum torque available from DAYTON AC hollow shaft right angle gearmotors in the listed series is 130 in-lb, as seen in the 6VEP6 model. This unit delivers 55 RPM output from a 0.25 hp three-phase input. Other models in the series provide lower torque ratings, ranging from 30 in-lb to 120 in-lb, with correspondingly higher output speeds. The torque rating is the maximum continuous torque the gearmotor can deliver under specified conditions. For applications requiring higher torque, consider a larger frame size or a different gear ratio. Always verify that the selected gearmotor's torque rating exceeds the application's peak torque requirements, including any shock loads.
