M12

M12 is a widely used circular connector standard defined by IEC 61076-2-101, specifying a 12 mm threaded locking interface for industrial sensors, actuators, encoders, and control devices. The standard originated in the early 1980s as a compact, robust alternative to larger connectors, and has since become a default interface for factory automation. M12 connectors are available in coded variants (A, B, C, D, X, etc.) to prevent mismating, with pole counts from 3 to 12 and current ratings typically up to 4 A per contact. They are commonly rated IP65, IP67, or IP68 when mated, and operate across temperature ranges such as -40 °C to +85 °C or +125 °C depending on materials. 3G Electric supplies M12 connectivity products including shielded cables, cordsets, receptacles, and field-wireable connectors. The line covers straight and right-angle configurations, male and female contacts, and various cable jacket materials such as polyurethane (PUR), polyvinyl chloride (PVC), and thermoplastic elastomer (TPE). Shielded variants are used where electromagnetic interference (EMI) must be controlled, such as encoder feedback lines in motor control and motion systems. Typical applications include connecting encoders, proximity sensors, photoelectric sensors, and valve islands in packaging, material handling, robotics, and assembly equipment. 3G Electric supports the M12 line with technical selection assistance, datasheet access, and global logistics. Buyers can specify coding, pole count, cable length, jacket material, and shielding according to the installation environment. The product range includes pre-molded cordsets with overmolded bodies for vibration resistance, as well as panel-mount receptacles with PCB or solder-cup terminations. For maintenance and retrofit, field-attachable connectors allow on-site assembly without specialized tooling. 3G Electric maintains inventory of common M12 configurations and can source less-common variants through its supplier network. The company serves plant engineers, maintenance managers, and procurement specialists who require documented specifications and consistent part numbers. All products are supplied with manufacturer part numbers and traceability. 3G Electric does not manufacture M12 components; it distributes products from established connector manufacturers. The M12 standard ensures interoperability across brands, but buyers should verify coding, pole count, and keying to avoid mismating. 3G Electric provides cross-reference support to help identify equivalent parts when a specific brand is not available. For harsh environments, stainless steel or nickel-plated brass coupling nuts and Viton or EPDM seals are available. For high-vibration applications, anti-vibration locking mechanisms or thread-locking adhesives may be specified. Cable lengths range from 0.5 m to 10 m or more, with custom lengths available on request. 3G Electric ships M12 products globally, with logistics support for both small orders and volume requirements. The company's catalog includes SKUs such as 52DK25, 52DK24, and 52DK23, which are shielded M12 cables with smooth polyurethane jackets for encoder connections. These cables are designed to maintain signal integrity in environments with vibration, oil, and electrical noise. 3G Electric's technical team can assist with selecting the appropriate M12 variant based on electrical load, environmental conditions, and mechanical constraints. For procurement, 3G Electric offers competitive pricing, lead-time information, and alternative part suggestions. The M12 line is part of 3G Electric's broader industrial automation portfolio, which also includes burners, pumps, gas controls, and related equipment. This allows customers to consolidate purchases and reduce supplier management overhead. 3G Electric's global reach means customers outside Singapore can access the same M12 products with international shipping. The company's focus is on providing accurate product data and responsive service to technical buyers.

Genuine
OEM Parts
Expert
Tech Support
1 Day
Quote Response
Worldwide
Origin
EXW Singapore
Collect or forward from our office
Datasheets on Request
Technical specs & drawings
1-Day Quote Response
Singapore-based team
Show
Page 1 of 1

About M12

M12 is a widely used circular connector standard defined by IEC 61076-2-101, specifying a 12 mm threaded locking interface for industrial sensors, actuators, encoders, and control devices. The standard originated in the early 1980s as a compact, robust alternative to larger connectors, and has since become a default interface for factory automation. M12 connectors are available in coded variants (A, B, C, D, X, etc.) to prevent mismating, with pole counts from 3 to 12 and current ratings typically up to 4 A per contact. They are commonly rated IP65, IP67, or IP68 when mated, and operate across temperature ranges such as -40 °C to +85 °C or +125 °C depending on materials. 3G Electric supplies M12 connectivity products including shielded cables, cordsets, receptacles, and field-wireable connectors. The line covers straight and right-angle configurations, male and female contacts, and various cable jacket materials such as polyurethane (PUR), polyvinyl chloride (PVC), and thermoplastic elastomer (TPE). Shielded variants are used where electromagnetic interference (EMI) must be controlled, such as encoder feedback lines in motor control and motion systems. Typical applications include connecting encoders, proximity sensors, photoelectric sensors, and valve islands in packaging, material handling, robotics, and assembly equipment. 3G Electric supports the M12 line with technical selection assistance, datasheet access, and global logistics. Buyers can specify coding, pole count, cable length, jacket material, and shielding according to the installation environment. The product range includes pre-molded cordsets with overmolded bodies for vibration resistance, as well as panel-mount receptacles with PCB or solder-cup terminations. For maintenance and retrofit, field-attachable connectors allow on-site assembly without specialized tooling. 3G Electric maintains inventory of common M12 configurations and can source less-common variants through its supplier network. The company serves plant engineers, maintenance managers, and procurement specialists who require documented specifications and consistent part numbers. All products are supplied with manufacturer part numbers and traceability. 3G Electric does not manufacture M12 components; it distributes products from established connector manufacturers. The M12 standard ensures interoperability across brands, but buyers should verify coding, pole count, and keying to avoid mismating. 3G Electric provides cross-reference support to help identify equivalent parts when a specific brand is not available. For harsh environments, stainless steel or nickel-plated brass coupling nuts and Viton or EPDM seals are available. For high-vibration applications, anti-vibration locking mechanisms or thread-locking adhesives may be specified. Cable lengths range from 0.5 m to 10 m or more, with custom lengths available on request. 3G Electric ships M12 products globally, with logistics support for both small orders and volume requirements. The company's catalog includes SKUs such as 52DK25, 52DK24, and 52DK23, which are shielded M12 cables with smooth polyurethane jackets for encoder connections. These cables are designed to maintain signal integrity in environments with vibration, oil, and electrical noise. 3G Electric's technical team can assist with selecting the appropriate M12 variant based on electrical load, environmental conditions, and mechanical constraints. For procurement, 3G Electric offers competitive pricing, lead-time information, and alternative part suggestions. The M12 line is part of 3G Electric's broader industrial automation portfolio, which also includes burners, pumps, gas controls, and related equipment. This allows customers to consolidate purchases and reduce supplier management overhead. 3G Electric's global reach means customers outside Singapore can access the same M12 products with international shipping. The company's focus is on providing accurate product data and responsive service to technical buyers.

Common Applications

  • Industrial automation — M12 shielded cable (e.g., SKU 52DK25) for encoder connections in motion control systems.
  • Robotics — M12 cordsets with PUR jacket for sensor and actuator wiring on articulated arms.
  • Packaging machinery — M12 connectors for photoelectric sensors and valve islands in high-vibration environments.
  • Material handling — M12 receptacles and cordsets for proximity sensors on conveyors and sorters.
  • Motor feedback — Shielded M12 cables (e.g., SKU 52DK24) for encoder signal transmission near variable-frequency drives.
  • Outdoor equipment — IP67/IP68 M12 connectors for washdown or weather-exposed sensor installations.

Frequently asked questions

Common questions about M12 from 3G Electric.

What is the difference between shielded and unshielded M12 cables?

Shielded M12 cables include a metallic foil or braid around the signal conductors to reduce electromagnetic interference (EMI). They are used in applications with variable-frequency drives, motors, or other noise sources, such as encoder feedback lines. Unshielded cables are lighter, more flexible, and lower cost, suitable for clean environments with low EMI. Shielding effectiveness depends on coverage percentage and grounding. For M12, the shield is typically connected to the coupling nut or a dedicated drain wire. 3G Electric stocks both types; selection depends on signal integrity requirements and cable routing.

What IP ratings are available for M12 connectors?

M12 connectors are commonly rated IP65, IP67, or IP68 when mated. IP65 protects against dust and water jets; IP67 allows temporary immersion up to 1 m for 30 minutes; IP68 allows continuous immersion under specified conditions. The actual rating depends on the connector's sealing materials (e.g., O-rings, gaskets) and the mating counterpart. For washdown or outdoor applications, IP67 or IP68 variants with stainless steel or nickel-plated brass hardware are often specified. 3G Electric can provide IP-rated M12 products; verify the rating in the datasheet for the specific part number.

Can M12 connectors be used for Ethernet or Profinet?

Yes, specific M12 variants are designed for industrial Ethernet and Profinet. These use D-coded or X-coded interfaces with 4 or 8 poles, respectively, and are rated for Category 5e or Category 6a performance. D-coded M12 supports 100 Mbit/s; X-coded supports 1 Gbit/s. They are used in harsh environments where standard RJ45 connectors are not suitable. 3G Electric supplies M12 Ethernet cordsets and receptacles; ensure the coding and pole count match the network requirement. Shielding and proper grounding are critical for reliable data transmission.

What is the typical current rating for M12 connectors?

M12 connectors typically carry 1 A to 4 A per contact, depending on pole count, contact size, and ambient temperature. Higher currents are possible with special designs, but standard M12 is not intended for power distribution. For motor or actuator power, verify the derating curve and consider the number of simultaneously loaded contacts. Voltage ratings are usually 30 V to 250 V, depending on coding and insulation. 3G Electric can provide current and voltage ratings for specific M12 part numbers; always confirm against the manufacturer's datasheet.

Are M12 connectors compatible across different manufacturers?

M12 is an international standard (IEC 61076-2-101), so connectors from different manufacturers are generally intermateable if they share the same coding, pole count, and keying. However, minor differences in tolerances, sealing, and materials can affect performance. For critical applications, it is advisable to use matched pairs from the same manufacturer or verify compatibility. 3G Electric supplies M12 products from established manufacturers and can provide cross-reference information to help identify equivalent parts.

What cable jacket materials are available for M12 cordsets?

Common jacket materials include polyurethane (PUR), polyvinyl chloride (PVC), and thermoplastic elastomer (TPE). PUR offers good resistance to oil, abrasion, and hydrolysis, making it suitable for harsh industrial environments. PVC is lower cost and adequate for general use. TPE provides flexibility and temperature resistance. The choice depends on exposure to chemicals, UV, temperature, and mechanical stress. 3G Electric stocks M12 cordsets with various jacket materials; the product datasheet lists the specific material and its ratings.
