Johnson Controls 3G-OTH-67698 — Technical Specifications
The JOHNSON CONTROLS M9109-GGC-5 is a non-fail-safe actuator for dampers and VAV boxes, featuring a self-centering clamping shaft with 90° stroke and CW/CCW rotation. It operates on 24V AC with a 0 to 10V DC output signal, includes an auxiliary switch, and uses a plug-in electrical connection. This actuator is compatible with building automation systems.
Technical Specifications
| Parameter | Value |
|---|---|
| Brand | JOHNSON CONTROLS |
| Shaft Type | Self-Centering Clamping |
| Input Voltage | 24V AC |
| Output Signal | 0 to 10V DC |
| Stroke Degree | 90° |
| Shaft Rotation | CW/CCW |
| Manufacturer Part Number | M9109-GGC-5 |
| Auxiliary Switch Included | Yes |
| Electrical Connection Type | Plug-In |
| For Use With Building Automation Systems | Building Automation System Compatible |
