Crydom 3G-OTH-36825 — Technical Specifications

Name: Crydom 3G-OTH-36825 CRYDOM Solid State Relay: DIN-Rail Mounted, 20 A Max Output Current, SCR, AC Output (MPN CKRA2420). Key specifications — Brand: CRYDOM; Current Type: AC; Electrical Connection: Box Clamp; Finger Safe: Yes; Input Current: 5 mA at 240 Vrms; Maximum Output Current without Heat Sink: 20 A; Mounting Style: DIN Rail; Output Voltage: 24 to 280V AC.
Brand: Crydom

CRYDOM Solid State Relay: DIN-Rail Mounted, 20 A Max Output Current, SCR, AC Output (MPN CKRA2420). Key specifications — Brand: CRYDOM; Current Type: AC; Electrical Connection: Box Clamp; Finger Safe: Yes; Input Current: 5 mA at 240 Vrms; Maximum Output Current without Heat Sink: 20 A; Mounting Style: DIN Rail; Output Voltage: 24 to 280V AC.

View Product & Quote

Technical Specifications

Parameter	Value
Brand	CRYDOM
Finger Safe	Yes
Current Type	AC
Input Current	5 mA at 240 Vrms
Mounting Style	DIN Rail
Output Voltage	24 to 280V AC
Switch Configuration	Form A
Voltage/Current Type	AC Output
Electrical Connection	Box Clamp
Manufacturer Part Number	CKRA2420
Maximum Output Current Without Heat Sink	20 A
