Crydom 3G-OTH-37869 — Technical Specifications

Name: Crydom 3G-OTH-37869 CRYDOM Dual Solid State Relay: Surface Mounted, 40 A Max Output Current, SCR, AC Output (MPN D2440D). Key specifications — Brand: CRYDOM; Current Type: AC; Electrical Connection: Screw Clamp; Finger Safe: No; Input Current: 12 mA; Maximum Output Current without Heat Sink: Not Recommended; Mounting Style: Panel; Output Voltage: 24 to 280V AC.
Brand: Crydom

The CRYDOM D2440D is a panel-mounted, dual solid-state relay with a Form A (SPST-NO) switch configuration and AC output. It operates with an input current of 12 mA and an output voltage range of 24 to 280V AC, featuring a screw-clamp electrical connection. The maximum output current without a heat sink is not recommended, and the relay is not finger-safe.

View Product & Quote

Technical Specifications

Parameter	Value
Brand	CRYDOM
Finger Safe	No
Current Type	AC
Input Current	12 mA
Mounting Style	Panel
Output Voltage	24 to 280V AC
Switch Configuration	Form A
Voltage/Current Type	AC Output
Electrical Connection	Screw Clamp
Manufacturer Part Number	D2440D
Maximum Output Current Without Heat Sink	Not Recommended
