Crydom 3G-OTH-37811 — Technical Specifications
The CRYDOM EL240A10-05 is a panel-mounted solid-state relay with a Form A (SPST-NO) switch configuration, providing an AC output from 24 to 280V AC. It features a DC input current of 21 mA, a maximum output current of 10 A (9 A without a heat sink), and quick-connect electrical connections. This surface-mounted relay is not finger-safe and is designed for DC current type control.
Technical Specifications
| Parameter | Value |
|---|---|
| Brand | CRYDOM |
| Finger Safe | No |
| Current Type | DC |
| Input Current | 21 mA |
| Mounting Style | Panel |
| Output Voltage | 24 to 280V AC |
| Switch Configuration | Form A |
| Voltage/Current Type | AC Output |
| Electrical Connection | Quick-Connect |
| Manufacturer Part Number | EL240A10-05 |
| Maximum Output Current Without Heat Sink | 9 A |
