OMRON Solid State Relay: Surface Mounted - Surface-Mounted Relays
OMRONSurface-Mounted Relays

OMRON Solid State Relay: Surface Mounted

The OMRON G3NA-225B-UTU DC5-24 is a surface-mounted solid-state relay with a Form A switch configuration and AC output. It accepts a DC input current of 17.4 to 35 A and delivers an output voltage of 24 to 240V AC…

SKU 3G-OTH-38503

Brand
OMRON
Item
Solid State Relay: Surface Mounted
Category
Surface-Mounted Relays
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

OMRON
Brand
OMRON
Finger Safe
Yes
Current Type
DC
Input Current
17.4 to 35 A
Mounting Style
Surface
Output Voltage
24 to 240V AC
Switch Configuration
Form A
Voltage/Current Type
AC Output
Electrical Connection
Screw Clamp
Manufacturer Part Number
G3NA-225B-UTU DC5-24
Maximum Output Current without Heat Sink
35 A
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

OMRON Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The OMRON G3NA-225B-UTU DC5-24 is a surface-mounted solid-state relay with a Form A switch configuration and AC output. It accepts a DC input current of 17.4 to 35 A and delivers an output voltage of 24 to 240V AC, with a maximum output current of 35 A without a heat sink. The relay features screw-clamp electrical connections and is finger-safe for added protection.
