ATC DIVERSIFIED ELECTRONICS Time-Delay Relay: Socket Mounted - Socket-Mounted Relays
ATC DIVERSIFIED ELECTRONICSSocket-Mounted Relays

ATC DIVERSIFIED ELECTRONICS Time-Delay Relay: Socket Mounted

The ATC DIVERSIFIED ELECTRONICS Time-Delay Relay is a socket-mounted relay with an Off Delay function. It features a dial adjustment method, a plug-in mounting style, and an input voltage of 24 to 240V AC. The relay…

SKU 3G-OTH-37718

Brand
ATC DIVERSIFIED ELECTRONICS
Item
Time-Delay Relay: Socket Mounted
Category
Socket-Mounted Relays
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

ATC DIVERSIFIED ELECTRONICS
Brand
ATC DIVERSIFIED ELECTRONICS
Input Voltage
24 to 240V AC
Delay Function
Off Delay
Mounting Style
Plug-In
Adjustment Method
Dial
Contact Rating (AC)
10 A @ 250V AC
Contact Rating (DC)
10 A @ 30V DC
Manufacturer Part Number
407C100F3X
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

ATC DIVERSIFIED ELECTRONICS Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The ATC DIVERSIFIED ELECTRONICS Time-Delay Relay is a socket-mounted relay with an Off Delay function. It features a dial adjustment method, a plug-in mounting style, and an input voltage of 24 to 240V AC. The relay has a contact rating of 10 A @ 250V AC and 10 A @ 30V DC, with a delay range of 1 second to 10 hours (MPN 407C100F3X).
