ELVSolenoid Valves

ELV Stainless steel solenoid steam valve D 1"1/4

ELV stainless steel solenoid steam valve with DN 1¼ connection handles steam applications up to 10 bar operating pressure and 35 mm passage diameter. Cv value of 16 delivers reliable flow control in industrial steam…

SKU 3G-CBM-03272

Also listed as: ELV 40010 · ELV-40010

Brand

ELV

Item

Stainless steel solenoid steam valve D 1"1/4

Local availability & support

Delivery: Worldwide DHL shipping from Singapore; 7–14 business days door-to-door for most destinations.
Payment: Invoicing in USD. Bank transfer (SWIFT) and corporate PO accepted.

Technical Specifications

ELV

fluid

Steam

cv value

16

connection

1"

max pressure bar

10

connection diameter

1"1/4

passage diameter mm

35

operating pressure bar

0.5 - 10

max fluid viscosity cst

50

max differential pressure bar

25

Datasheet Content

Electrovannes inox NF vapeur                                                     Code

Electrovanne vapeur 3/8”                                                                           ELV40002


Electrovanne vapeur 1/2”                                                                           ELV40004


Electrovanne vapeur 3/4”                                                                           ELV40006


Electrovanne vapeur 1”                                                                             ELV40008


Electrovanne vapeur 1”1/4                                                                          3G-CBM-03272


Electrovanne vapeur 1”1/2                                                                          ELV40012



Caractéristiques techniques
            Modèle             ELV40002   ELV40004   ELV40006     ELV40008       3G-CBM-03272   ELV40012    ELV40014
Diamètre Raccord                3/8”       1/2”       3/4”           1”          1”1/4      1”1/2         2”
Diamètre passage               15mm       15mm       20mm          25mm          35mm       35mm         50mm
Pression différentielle max.     25         25         25            25            25         25          25
Valeur CV                        4.5        4.5        9.3          13.2           16         26          48
Dim. A mm                        75         75         85           100           120        120         150
Dim. C mm                       129        129        141           148           168        168         190
Viscosité fluide                                             Moins de 50 CST
Fluide                                                             Vapeur
Pression fonctionnement                                         0.5 ~ 10 bar
Pression maxi                                                      10 bar
Température maxi                                                5°C ~ 180°C
Tension                                                      +/- 10% - AC230V
Matériel corps                                                   Acier inox
Membrane                                                            Teflon
Mode opération                                                  Action directe
Type                                                        Normalement fermée


PIÈCES DE RECHANGES POUR VANNES
            Modèle             ELV40002   ELV40004   ELV40006     ELV40008       3G-CBM-03272   ELV40012    ELV40014
Référence bobine 220 V         ELV80515   ELV80515   ELV80515     ELV80515       ELV80515   ELV80515    ELV80515
Référence bobine 110 V            -          -          -             -             -          -           -
Référence bobine AC 48 V          -          -          -             -             -          -           -
Référence bobine AC 24 V          -          -          -             -             -          -           -
Référence bobine AC 12 V          -          -          -             -             -          -           -
Référence bobine DC 24 V       ELV81515   ELV81515   ELV81515     ELV81515       ELV81515   ELV81515    ELV81515
Référence bobine DC 12 V       ELV81530   ELV81530   ELV81530     ELV81530       ELV81530   ELV81530    ELV81530
Référence membrane NBR            -          -          -             -             -          -           -
Référence membrane EPDM           -          -          -             -             -          -           -
Référence membrane VITON          -          -          -             -             -          -           -


                                                                                                                   255

Technical Documents

(1)

Technical Document 1

PDF Document

Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.

Talk to an engineer

Ask a question

ELV Products

3G Electric (S) Pte. Ltd. — Singapore

Product Description

Frequently Asked Questions

Where can I buy an ELV ELV40010 solenoid steam valve in your region?

3G Electric stocks and sources the ELV ELV40010 stainless steel solenoid steam valve. We deliver to your location with full customs documentation support and USD invoicing. Lead time available on request.

What is the lead time and delivery for this ELV steam valve to your region?

Lead time on request. 3G Electric handles all logistics and customs clearance for delivery to your location, your location, and CALABARZON industrial zones. Standard process includes customs documentation and USD invoicing.

What steam pressure and flow capacity does the ELV ELV40010 handle?

The ELV40010 operates from 0.5 to 10 bar with a Cv value of 16. It features a 35mm passage diameter and DN 1¼ stainless steel connection, designed for reliable on-off switching in automated steam systems up to 10 bar maximum pressure.

Used in

Common applications for ELV

Pneumatic automation and directional control — ELV 2/2-way and 3/2-way pilot-operated solenoid valves in compressed-air circuits

Fluid-power machinery — ELV cavity cartridges and manifold-integrated solenoids in hydraulic and lubrication systems

Packaging and filling equipment — ELV proportional and on-off solenoid valves for rapid actuation and media switching

Water treatment and circulation systems — ELV valves rated for continuous water flow control and process isolation

Gas burner and combustion control — ELV solenoid coils for gas isolation and pilot fuel regulation in industrial burner systems

Maintenance and retrofit projects — ELV replacement solenoid coils and membrane kits for in-service valve replacement without removing the valve body
