ELVSolenoid Valves

ELV Stainless steel steam solenoid valve D 1"1/2

ELV stainless steel steam solenoid valve for industrial steam systems, rated to 10 bar with DN1½ connections and 35 mm passage diameter. Handles operating pressures from 0.5 to 10 bar, suitable for process control…

SKU 3G-CBM-03273

Also listed as: ELV 40012 · ELV-40012

Brand

ELV

Item

Stainless steel steam solenoid valve D 1"1/2

Local availability & support

Delivery: Worldwide DHL shipping from Singapore; 7–14 business days door-to-door for most destinations.
Payment: Invoicing in USD. Bank transfer (SWIFT) and corporate PO accepted.

Technical Specifications

ELV

fluid

steam

cv value

26

connection

1"

connection size

1"1/2

max pressure bar

10

fluid viscosity cst

< 50

passage diameter mm

35

operating pressure bar

0.5 - 10

max differential pressure bar

25

Datasheet Content

Electrovannes inox NF vapeur                                                     Code

Electrovanne vapeur 3/8”                                                                           ELV40002


Electrovanne vapeur 1/2”                                                                           ELV40004


Electrovanne vapeur 3/4”                                                                           ELV40006


Electrovanne vapeur 1”                                                                             ELV40008


Electrovanne vapeur 1”1/4                                                                          ELV40010


Electrovanne vapeur 1”1/2                                                                          3G-CBM-03273



Caractéristiques techniques
            Modèle             ELV40002   ELV40004   ELV40006     ELV40008       ELV40010   3G-CBM-03273    ELV40014
Diamètre Raccord                3/8”       1/2”       3/4”           1”          1”1/4      1”1/2         2”
Diamètre passage               15mm       15mm       20mm          25mm          35mm       35mm         50mm
Pression différentielle max.     25         25         25            25            25         25          25
Valeur CV                        4.5        4.5        9.3          13.2           16         26          48
Dim. A mm                        75         75         85           100           120        120         150
Dim. C mm                       129        129        141           148           168        168         190
Viscosité fluide                                             Moins de 50 CST
Fluide                                                             Vapeur
Pression fonctionnement                                         0.5 ~ 10 bar
Pression maxi                                                      10 bar
Température maxi                                                5°C ~ 180°C
Tension                                                      +/- 10% - AC230V
Matériel corps                                                   Acier inox
Membrane                                                            Teflon
Mode opération                                                  Action directe
Type                                                        Normalement fermée


PIÈCES DE RECHANGES POUR VANNES
            Modèle             ELV40002   ELV40004   ELV40006     ELV40008       ELV40010   3G-CBM-03273    ELV40014
Référence bobine 220 V         ELV80515   ELV80515   ELV80515     ELV80515       ELV80515   ELV80515    ELV80515
Référence bobine 110 V            -          -          -             -             -          -           -
Référence bobine AC 48 V          -          -          -             -             -          -           -
Référence bobine AC 24 V          -          -          -             -             -          -           -
Référence bobine AC 12 V          -          -          -             -             -          -           -
Référence bobine DC 24 V       ELV81515   ELV81515   ELV81515     ELV81515       ELV81515   ELV81515    ELV81515
Référence bobine DC 12 V       ELV81530   ELV81530   ELV81530     ELV81530       ELV81530   ELV81530    ELV81530
Référence membrane NBR            -          -          -             -             -          -           -
Référence membrane EPDM           -          -          -             -             -          -           -
Référence membrane VITON          -          -          -             -             -          -           -


                                                                                                                   255

Technical Documents

(1)

Technical Document 1

PDF Document

Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.

Talk to an engineer

Ask a question

ELV Products

3G Electric (S) Pte. Ltd. — Singapore

Product Description

Frequently Asked Questions

Where can I buy the ELV40012 steam solenoid valve in your region?

3G Electric stocks and sources the ELV40012 solenoid valve with delivery to your location. We handle customs documentation, USD invoicing, and full logistics support. Contact us for pricing and lead time.

What is the lead time for the ELV40012 valve?

Lead time varies based on origin availability. 3G Electric sources this valve to order with documentation and delivery handled end-to-end to your region locations. Request a quote for current lead times and delivery schedule.

What are the operating specifications of the ELV40012 steam solenoid valve?

The ELV40012 is rated for steam at 0.5–10 bar operating pressure with DN1½ (1" connection) and a 35 mm passage diameter. Maximum differential pressure is 25 bar, Cv value 26. Stainless steel construction suits process control and automation systems.

Used in

Common applications for ELV

Pneumatic automation and directional control — ELV 2/2-way and 3/2-way pilot-operated solenoid valves in compressed-air circuits

Fluid-power machinery — ELV cavity cartridges and manifold-integrated solenoids in hydraulic and lubrication systems

Packaging and filling equipment — ELV proportional and on-off solenoid valves for rapid actuation and media switching

Water treatment and circulation systems — ELV valves rated for continuous water flow control and process isolation

Gas burner and combustion control — ELV solenoid coils for gas isolation and pilot fuel regulation in industrial burner systems

Maintenance and retrofit projects — ELV replacement solenoid coils and membrane kits for in-service valve replacement without removing the valve body
