ELV Stainless steel steam solenoid valve D 1/2

ELV stainless steel steam solenoid valve with 1/2" port handles steam applications up to 10 bar operating pressure and 25 bar maximum differential pressure. Cv value of 4.5 suits industrial steam control systems…

SKU 3G-CBM-03269

Also listed as: ELV 40004 · ELV-40004

Brand

ELV

Item

Stainless steel steam solenoid valve D 1/2

Local availability & support

Delivery: Worldwide DHL shipping from Singapore; 7–14 business days door-to-door for most destinations.
Payment: Invoicing in USD. Bank transfer (SWIFT) and corporate PO accepted.

Technical Specifications

ELV

fluid

Steam

cv value

4.5

port size

1/2"

max pressure

10 bar

max viscosity

50 CST

passage diameter

15 mm

operating pressure

0.5 - 10 bar

max differential pressure

25 bar

Datasheet Content

Electrovannes inox NF vapeur                                                     Code

Electrovanne vapeur 3/8”                                                                           ELV40002


Electrovanne vapeur 1/2”                                                                           3G-CBM-03269


Electrovanne vapeur 3/4”                                                                           ELV40006


Electrovanne vapeur 1”                                                                             ELV40008


Electrovanne vapeur 1”1/4                                                                          ELV40010


Electrovanne vapeur 1”1/2                                                                          ELV40012



Caractéristiques techniques
            Modèle             ELV40002   3G-CBM-03269   ELV40006     ELV40008       ELV40010   ELV40012    ELV40014
Diamètre Raccord                3/8”       1/2”       3/4”           1”          1”1/4      1”1/2         2”
Diamètre passage               15mm       15mm       20mm          25mm          35mm       35mm         50mm
Pression différentielle max.     25         25         25            25            25         25          25
Valeur CV                        4.5        4.5        9.3          13.2           16         26          48
Dim. A mm                        75         75         85           100           120        120         150
Dim. C mm                       129        129        141           148           168        168         190
Viscosité fluide                                             Moins de 50 CST
Fluide                                                             Vapeur
Pression fonctionnement                                         0.5 ~ 10 bar
Pression maxi                                                      10 bar
Température maxi                                                5°C ~ 180°C
Tension                                                      +/- 10% - AC230V
Matériel corps                                                   Acier inox
Membrane                                                            Teflon
Mode opération                                                  Action directe
Type                                                        Normalement fermée


PIÈCES DE RECHANGES POUR VANNES
            Modèle             ELV40002   3G-CBM-03269   ELV40006     ELV40008       ELV40010   ELV40012    ELV40014
Référence bobine 220 V         ELV80515   ELV80515   ELV80515     ELV80515       ELV80515   ELV80515    ELV80515
Référence bobine 110 V            -          -          -             -             -          -           -
Référence bobine AC 48 V          -          -          -             -             -          -           -
Référence bobine AC 24 V          -          -          -             -             -          -           -
Référence bobine AC 12 V          -          -          -             -             -          -           -
Référence bobine DC 24 V       ELV81515   ELV81515   ELV81515     ELV81515       ELV81515   ELV81515    ELV81515
Référence bobine DC 12 V       ELV81530   ELV81530   ELV81530     ELV81530       ELV81530   ELV81530    ELV81530
Référence membrane NBR            -          -          -             -             -          -           -
Référence membrane EPDM           -          -          -             -             -          -           -
Référence membrane VITON          -          -          -             -             -          -           -


                                                                                                                   255

Technical Documents

(1)

Technical Document 1

PDF Document

Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.

Talk to an engineer

Ask a question

ELV Products

3G Electric (S) Pte. Ltd. — Singapore

Product Description

Frequently Asked Questions

Where can I source the ELV40004 steam solenoid valve in your region?

3G Electric supplies the ELV40004 stainless steel steam solenoid valve with delivery to your location. We manage all logistics, customs clearance (customs), and USD invoicing. Lead time on request.

What is the lead time for ELV40004 delivery to your region?

Lead time depends on current stock and your delivery location within your region. Contact 3G Electric for a quote—we handle end-to-end import logistics and can expedite urgent orders.

What applications is the ELV40004 steam valve suited for?

The ELV40004 is a stainless steel on-off solenoid valve rated for steam at 10 bar operating pressure and 25 bar max differential pressure. Its Cv value of 4.5 suits industrial steam control systems requiring reliable modulation and long service life.
