ELVSolenoid Valves

ELV Stainless steel steam solenoid valve D 3/4

ELV stainless steel steam solenoid valve with DN 3/4" connection, rated for 0.5–10 bar operating pressure and 25 bar maximum differential pressure. Features Cv value of 9.3 and 20 mm passage diameter. Designed for…

SKU 3G-CBM-03270

Also listed as: ELV 40006 · ELV-40006

Brand

ELV

Item

Stainless steel steam solenoid valve D 3/4

Local availability & support

Delivery: Worldwide DHL shipping from Singapore; 7–14 business days door-to-door for most destinations.
Payment: Invoicing in USD. Bank transfer (SWIFT) and corporate PO accepted.

Technical Specifications

ELV

fluid

steam

cv value

9.3

dimension a mm

85

dimension c mm

141

connection size

3/4"

max pressure bar

10

fluid viscosity cst

< 50

passage diameter mm

20

operating pressure bar

0.5 ~ 10

max differential pressure bar

25

Datasheet Content

Electrovannes inox NF vapeur                                                     Code

Electrovanne vapeur 3/8”                                                                           ELV40002


Electrovanne vapeur 1/2”                                                                           ELV40004


Electrovanne vapeur 3/4”                                                                           3G-CBM-03270


Electrovanne vapeur 1”                                                                             ELV40008


Electrovanne vapeur 1”1/4                                                                          ELV40010


Electrovanne vapeur 1”1/2                                                                          ELV40012



Caractéristiques techniques
            Modèle             ELV40002   ELV40004   3G-CBM-03270     ELV40008       ELV40010   ELV40012    ELV40014
Diamètre Raccord                3/8”       1/2”       3/4”           1”          1”1/4      1”1/2         2”
Diamètre passage               15mm       15mm       20mm          25mm          35mm       35mm         50mm
Pression différentielle max.     25         25         25            25            25         25          25
Valeur CV                        4.5        4.5        9.3          13.2           16         26          48
Dim. A mm                        75         75         85           100           120        120         150
Dim. C mm                       129        129        141           148           168        168         190
Viscosité fluide                                             Moins de 50 CST
Fluide                                                             Vapeur
Pression fonctionnement                                         0.5 ~ 10 bar
Pression maxi                                                      10 bar
Température maxi                                                5°C ~ 180°C
Tension                                                      +/- 10% - AC230V
Matériel corps                                                   Acier inox
Membrane                                                            Teflon
Mode opération                                                  Action directe
Type                                                        Normalement fermée


PIÈCES DE RECHANGES POUR VANNES
            Modèle             ELV40002   ELV40004   3G-CBM-03270     ELV40008       ELV40010   ELV40012    ELV40014
Référence bobine 220 V         ELV80515   ELV80515   ELV80515     ELV80515       ELV80515   ELV80515    ELV80515
Référence bobine 110 V            -          -          -             -             -          -           -
Référence bobine AC 48 V          -          -          -             -             -          -           -
Référence bobine AC 24 V          -          -          -             -             -          -           -
Référence bobine AC 12 V          -          -          -             -             -          -           -
Référence bobine DC 24 V       ELV81515   ELV81515   ELV81515     ELV81515       ELV81515   ELV81515    ELV81515
Référence bobine DC 12 V       ELV81530   ELV81530   ELV81530     ELV81530       ELV81530   ELV81530    ELV81530
Référence membrane NBR            -          -          -             -             -          -           -
Référence membrane EPDM           -          -          -             -             -          -           -
Référence membrane VITON          -          -          -             -             -          -           -


                                                                                                                   255

Technical Documents

(1)

Technical Document 1

PDF Document

Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.

Talk to an engineer

Ask a question

ELV Products

3G Electric (S) Pte. Ltd. — Singapore

Product Description

Frequently Asked Questions

Where can I buy the ELV40006 steam solenoid valve in your region?

3G Electric supplies the ELV40006 stainless steel steam solenoid valve for delivery to your location, your location, and CALABARZON. We handle customs documentation, customs clearance, and USD invoicing. Lead time on request.

What is the lead time for the ELV40006 solenoid valve to your region?

The ELV40006 is available to order. Exact lead time depends on current stock and destination within your region. Contact 3G Electric for a quote and delivery schedule. We manage all logistics and customs.

What are the pressure and flow specifications for the ELV40006 steam valve?

The ELV40006 operates at 0.5–10 bar with a maximum differential pressure of 25 bar. Cv value is 9.3 with a 20 mm passage diameter. DN 3/4" connection, rated for steam applications up to 10 bar maximum.
