Allanson UVB248T6-1800-MV UV Ballast – Program Start
UVB248T6-1800-MV UV BALLAST – Program Start
SKU 3G-OTH-03023
Local availability & support
- Payment
- Invoicing in USD. Bank transfer (SWIFT) and corporate PO accepted.
Need installation or engineering help?
Ask a question
Product Description
UVB248T6-1800-MV UV BALLAST – Program Start
Frequently Asked Questions
What is the Allanson UVB248T6-1800-MV UV ballast used for?
The Allanson UVB248T6-1800-MV is a program-start UV ballast designed to power two amalgam UV lamps, such as Heraeus NNI 80/61 or Philips TUV115W VHO. It is commonly used in water treatment, air purification, and industrial UV curing systems where reliable lamp ignition and stable output are required.
What are the specifications of the Allanson UVB248T6-1800-MV?
The Allanson UVB248T6-1800-MV operates at 120-240 VAC, 50/60 Hz, with 310W input power and 1800 mA lamp current. It drives two amalgam lamps from 20 to 48 inches. The ballast measures 16.57 x 3.2 x 2.73 inches, weighs 8.75 lb, and carries UL/cUL, Class P, and Type 1 outdoor approvals.
Where to buy the Allanson UVB248T6-1800-MV in Singapore?
3G Electric supplies the Allanson UVB248T6-1800-MV UV ballast to customers in Singapore. We handle logistics, customs clearance, and delivery to your facility. Contact our team for a quotation and lead time on this program-start ballast.
How to install the Allanson UVB248T6-1800-MV ballast?
Mount the Allanson UVB248T6-1800-MV in a dry, ventilated area within 0-40°C ambient temperature. Connect input voltage (120-240 VAC) per the wiring diagram, ensuring proper grounding. Use the correct lamp type and length (20-48 inches) for program-start operation. Do not exceed the case temperature limit of 75°C.
Used in
Common applications for AllansonAllanson Products
3G Electric supplies Allanson uv ballasts. We supply genuine products with in-stock availability on common SKUs, technical documentation, commissioning support, and warranty service — worldwide.
