AllansonUV Ballasts

Allanson UVB248T6-2100-48VDC UV Ballast – Program Start

UVB248T6-2100-48VDC UV BALLASTS – Program Start

SKU 3G-OTH-03024

Brand

Allanson

Item

UVB248T6-2100-48VDC UV Ballast – Program Start

Part Number

UVB248T6210048VDC

Local availability & support

Payment: Invoicing in USD. Bank transfer (SWIFT) and corporate PO accepted.

Compliance & shipping

Hazardous material: Not classified as hazardous

Technical Specifications

Allanson

Manufacturer Part Number

UVB248T6210048VDC

Size

17.0"x3.6"x2.2"

Lamps

2

Weight

8.0 lb

Lamp mA

2100

Lamp Type

Amalgam

Input Lamps

2

Lamp Length

20" to 48"

Potted Case

PC Board

Input Voltage

48V

Input Wattage

430

Technical Documents

(1)

Technical Document 1

PDF Document

Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.

Talk to an engineer

Ask a question

Allanson Products

3G Electric (S) Pte. Ltd. — Singapore

Product Description

UVB248T6-2100-48VDC UV BALLASTS – Program Start

Frequently Asked Questions

What is the Allanson UVB248T6-2100-48VDC UV ballast used for?

The Allanson UVB248T6-2100-48VDC is a program-start UV ballast designed to power two amalgam UV lamps, such as the TUV-200MSG or TUV200W XPT. It is commonly used in water treatment, air purification, and industrial disinfection systems requiring reliable, high-efficiency lamp operation.

What are the specifications of the Allanson UVB248T6-2100-48VDC?

The Allanson UVB248T6-2100-48VDC operates at 48 VDC input (range 35–60 VDC), draws 9.0 A, and delivers 430 W. It drives two amalgam lamps at 2100 mA, with dimensions 17.0" x 3.6" x 2.2" and weight 8.0 lb. It features program start, >90% efficiency, and UL/cUL recognition.

Where to buy the Allanson UVB248T6-2100-48VDC in Singapore?

3G Electric supplies the Allanson UVB248T6-2100-48VDC UV ballast to customers in Singapore. We handle logistics, customs clearance, and delivery to your facility. Contact our team for pricing and lead time on this program-start ballast for amalgam lamps.

How to install the Allanson UVB248T6-2100-48VDC ballast?

Installation should follow the wiring diagram provided by Allanson. Ensure the 48 VDC input is within the 35–60 VDC range and that the ballast is mounted in a location with ambient temperature 0–40 °C. Connect dry contacts for status monitoring and verify lamp compatibility with the 2100 mA output.
