UVB148T6-2200-MV UV BALLAST – Program Start
SKU 3G-OTH-03011
Local availability & support
- Payment
- Invoicing in USD. Bank transfer (SWIFT) and corporate PO accepted.
Need installation or engineering help?
Ask a question
Product Description
UVB148T6-2200-MV UV BALLAST – Program Start
Frequently Asked Questions
What is the Allanson UVB148T6-2200-MV UV ballast used for?
The Allanson UVB148T6-2200-MV is a program-start UV ballast designed to power one amalgam lamp, such as Heraeus NNI 200/108 or Philips TUV180W XPT. It is commonly used in water treatment, air purification, and industrial UV curing systems where reliable lamp ignition and stable output are required.
What are the specifications of the Allanson UVB148T6-2200-MV?
The Allanson UVB148T6-2200-MV operates at 120-240 VAC, 50/60 Hz, with an input power of 220 W and input current of 1.75 A at 120 V or 0.90 A at 240 V. It drives one amalgam lamp at 2200 mA, has a lamp current crest factor of 1.7 or less, and is UL/cUL listed with a Class P, outdoor, Type 1 rating.
Where to buy the Allanson UVB148T6-2200-MV in Singapore?
3G Electric supplies the Allanson UVB148T6-2200-MV UV ballast to customers in Singapore. We handle logistics, customs clearance, and delivery to your facility. Contact our team for pricing and lead time on this program-start ballast for amalgam lamps.
How to install the Allanson UVB148T6-2200-MV ballast?
Install the Allanson UVB148T6-2200-MV in a dry, ventilated area with ambient temperature between 0-40 °C. Ensure the input voltage matches 120-240 VAC and follow the wiring diagram for one amalgam lamp. The potted case allows outdoor mounting, but keep the case temperature below 75 °C for reliable operation.
