Allanson UVB264T6-1400-230V UV Ballast – Instant Start

The Allanson UVB264T6-1400-230V is an instant-start UV ballast designed to power one or two amalgam UV lamps, such as the GA64T5L or GPHA1554T5L, in water treatment, air purification, and industrial UV curing systems. It operates at 230V input and delivers 1400 mA lamp current for reliable lamp ignition and stable output.

The Allanson UVB264T6-1400-230V is a 350W instant-start ballast with 230V ±10% input, 50/60 Hz, and 1.60A input current. It supports one or two amalgam lamps from 36 to 64 inches, has a power factor above 95%, efficiency above 90%, and UL/cUL Class P recognition. Dimensions are 13.7 x 3.1 x 2.75 inches.

3G Electric supplies the Allanson UVB264T6-1400-230V UV ballast to customers in Singapore. We handle logistics, customs clearance, and delivery to your facility. Contact our team for a quote and lead time on this item. We source genuine Allanson ballasts for industrial UV applications.

Install the Allanson UVB264T6-1400-230V in a dry, ventilated location with ambient temperature between 0 and 45°C. Connect the 230V supply to the input terminals per the wiring diagram, and attach the lamp leads to the appropriate sockets. Ensure the case temperature stays below 75°C and use a Class P rated enclosure for outdoor installations.
