Allanson UVB248T5-425-MV UV Ballast – Instant Start

UVB248T5-425-MV UV BALLAST – Instant Start

SKU 3G-OTH-03022

Brand

Allanson

Item

UVB248T5-425-MV UV Ballast – Instant Start

Part Number

UVB248T5425MV

Local availability & support

Payment: Invoicing in USD. Bank transfer (SWIFT) and corporate PO accepted.

Technical Specifications

Allanson

Manufacturer Part Number

UVB248T5425MV

Size

8.5"x2.2"x1.75"

Lamps

1 or 2

Weight

2.55 lb

Lamp mA

425

Lamp Type

Standard

Input Lamps

1 or 2

Lamp Length

24″ to 48″

Potted Case

Yes

Input Voltage

120V-277V

Input Wattage

135

Technical Documents

(1)

Technical Document 1

PDF Document

Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.

Talk to an engineer

Ask a question

Allanson Products

3G Electric (S) Pte. Ltd. — Singapore

Product Description

UVB248T5-425-MV UV BALLAST – Instant Start

Frequently Asked Questions

What is the Allanson UVB248T5-425-MV UV ballast used for?

The Allanson UVB248T5-425-MV is an instant-start electronic ballast designed to power one or two standard UV lamps, such as G48T5L or G36T5L, in water treatment, air purification, and industrial UV curing systems. It operates at 425 mA and supports lamp lengths from 24 to 48 inches.

What are the specifications of the Allanson UVB248T5-425-MV ballast?

The Allanson UVB248T5-425-MV ballast operates on 120-277 VAC input, draws 1.10 A at 120 V or 0.50 A at 277 V, delivers 128 W full-load power, and has a power factor above 95%. It is UL/cUL listed, Class P, indoor Type 1, with a sound rating of A and a case temperature limit of 75 °C.

Where to buy the Allanson UVB248T5-425-MV ballast in Singapore?

3G Electric supplies the Allanson UVB248T5-425-MV ballast to customers in Singapore. We handle logistics, customs clearance, and delivery to your facility. Contact our team for a quote and lead time on this instant-start UV ballast.

How to install the Allanson UVB248T5-425-MV ballast?

Install the Allanson UVB248T5-425-MV ballast in a dry, indoor location with ambient temperature between 0 and 40 °C. Follow the wiring diagram for 120-277 V input, connect one or two 425 mA UV lamps, and ensure the case temperature stays below 75 °C. Use a qualified electrician for installation.
