EATON Toggle Switch: 3 Position, 3 Connections, SPST, Solder Lug Connection - Panel-Mount Toggle Switches
EATONPanel-Mount Toggle Switches

EATON Toggle Switch: 3 Position, 3 Connections, SPST, Solder Lug Connection

The EATON 7500 Series Toggle Switch (MPN 7505K4) is a panel-mount, single-pole single-throw (SPST) switch with a 3-position On/None/On configuration. It features a solder lug connection and is rated for 10 A at 250 V…

SKU 3G-OTH-33008

Brand
EATON
Item
Toggle Switch: 3 Position, 3 Connections, SPST, Solder Lug Connection
Category
Panel-Mount Toggle Switches
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

EATON
Manufacturer Part Number
7505K4
Series
7500
Type
SPST, Solder Lug Connection
Horsepower
3/4 hp @ 250V AC
Connections
3
AC Contact Rating
10 A @ 250 V
Switch Function Configuration
On/None/On
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

EATON Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The EATON 7500 Series Toggle Switch (MPN 7505K4) is a panel-mount, single-pole single-throw (SPST) switch with a 3-position On/None/On configuration. It features a solder lug connection and is rated for 10 A at 250 V AC, with a horsepower rating of 3/4 hp at 250 V AC.
