Fantini Cosmi Air flow controller FF71A

The Fantini Cosmi FF71A is an air flow controller with SPDT contact switching, rated for -20 to 70 °C operation. It features a flexible AISI 316L stainless steel blade and maximum flow speeds up to 3 m/s across…

SKU 3G-CBM-03590

Also listed as: FAN 18002 · FAN-18002

Brand

Fantini Cosmi

Item

Air flow controller FF71A

Local availability & support

Delivery: Worldwide DHL shipping from Singapore; 7–14 business days door-to-door for most destinations.
Payment: Invoicing in USD. Bank transfer (SWIFT) and corporate PO accepted.

Technical Specifications

Fantini Cosmi

type

FF71A

cable gland

nylon G 3/8

contact type

SPDT

max temperature

50 °C

flange connection

PVC 5mm

protection degree

IP54

temperature range

-20 to 70 °C

blade size standard

50x165 mm

flow speed max 160cm2

1.4 m/s

flow speed max 320cm2

2.2 m/s

flow speed max 640cm2

3 m/s

flow speed max 1280cm2

3 m/s

flexible blade material

AISI 316L stainless steel

Datasheet Content

CONTROLE DE FLUX POUR AIR 3G-CBM-03590

       EMPLOI
       -Pour contrôler et régler un flux d'air dans des installations de
        conditionnement, séchage, refroidissement, etc.
       -Pour la commande de brûleurs, pompes, vannes,
        signalisations d'alarme, etc.

       FONCTIONNEMENT ET INSTALLATION
       -Une palette flexible, est poussée par le flux d'air qu'on doit
        contrôler. Le mouvement est transmis à un microinterrupteur
        SPDT.
       -Le contrôle de flux doit être installé sur un tronçon de conduite
        horizontale, loin de coudes, ventilateurs et points où des
        turbulences excessives peuvent se créer.

       CARACTERISTIQUES TECHNIQUES
       -Degré de d'isolation: II
       -Degré de essai: II
       -Type d'action : 1B
       -Normal pollution
       -Boîtier en matériau antichoc, vis imperdables
       -Palette flexible en acier inox AISI 316L. (standard 50x165)
       -Raccords électriques sur Faston 6,35 (en dotation).
       -Presse-câble en nylon G 3/8.
       -Equerres et vis de terre.
       -Régulation du point d'intervention avec vis de calibrage.
       -Raccord avec bride à PVC, épaisseur 5mm                                                                     105                 80
                                                                                                                                        62

       NORMES ET HOMOLOGATION
       -Répondant aux normes CEI EN 60730-1                                                                                                     90


       CARACTERISTIQUES ELECTRIQUES
                                                                                                                                                       260
       -Microinterrupteur unipolaire en commutation SPDT
       -Portée contacts: 10 (4)A / 250V~                                                                                                        165
       -FLUX EN AUGMENTATION:
       -Ouvre le contact C-NC                                                                                             10
        en ferme le contact C-NO
       -FLUX EN DIMINUTION:
       -Ferme le contact C-NC
        en ouvre le contact C-NO                                                                                                        75




                         Surface      Vitesse max flux en Vitesse min flux en      Température      Température   Degre de          Poids             Pieces
        TYPE            du conduit       augmentation         diminution            d'utilisation    maximale     protection       unitaire
                                                                                                     ambiante
                           cm2              m/sec               m/sec                   °C              °C                              Kg.            N°.

                           160               1,4                 0,6

        FF71A              320               2,2                 1,2                -20 ÷ 70             50          IP54                0,36
                           640               3                   1,6
                         1280                3                   1,7



                                                                                Exemple de connections électriques, ferme l'alimentation se le
                                                                                flux d'air dans la tuyauteries est en diminution.



                                                                                                                               C




                                                                                                                          NC       NO
                                                                                                                                              RECHARGE
                                                                                                                                              STOP



                                                                            FF71 NC C NO



9807
                                                                                                                                                             FF71
