Fantini Cosmi Weighted PVC probe EA19

Fantini Cosmi weighted PVC probe EA19 is a thermostat switch for temperature monitoring in industrial heating and cooling systems. It features a G 3/8" connection and handles temperatures up to 160°C at maximum…

SKU 3G-CBM-03497

Also listed as: FAN 02014 · FAN-02014

Brand

Fantini Cosmi

Item

Weighted PVC probe EA19

Local availability & support

Delivery: Worldwide DHL shipping from Singapore; 7–14 business days door-to-door for most destinations.
Payment: Invoicing in USD. Bank transfer (SWIFT) and corporate PO accepted.

Technical Specifications

Fantini Cosmi

connection

G 3/8"

maximum temperature

160°C

maximum operating pressure

10 bar

Datasheet Content

FAN02012 à 22
temperatures

                                                                                                               .

                                                                        Dimensions (mm)
                                                                                                  60                   G 3/8

FEATURES
Maximum operating pressure: 10 bar.
Maximum temperature: 160 ° C.
Male connection G 3/8”.

INSTALLATION
Connection between the probe and the level control is realized through a single-pole flexible cable (not supplied).
Electrode probe is not supplied as well.

ACCESSORIES
code FAN02020 Stainless steel electrode AISI 303 - 1 m length.
code FAN02022 Stainless steel electrode AISI 303 - 2 m length.

EA19 Ballasted PVC probe with electrode
SUITABLE FOR WELLS, storage tanks and reservoirs FOR IRRIGATION.

                                                                                                              Ø 4 мм

                                                                                          16÷20

                                                                        Dimensions (mm)
                                                                                                              70

                                                                                                       Ø 20

FEATURES
Operation at atmospheric pressure.
Maximum temperature: 80°C.
Stainless steel electrode AISI 303 (included).
Cable gland G1/4”.
Connection cable 1x1,5mm2 (not included).

INSTALLATION
Connection between the probe and the level control is realized through a single-pole flexible cable (not supplied).
EA20 Stainless steel electronic probe AISI 303
suitable for wells and tanks under pressure and/or for high temperatures.

                                                            Dimensions (mm)
                                                                                    165
                                                                                           G 3/8

                                                                                           3,5

FEATURES
Maximum operating pressure: 35 bar.
Maximum temperature: 250°C.
Male connection G3/8“.

INSTALLATION
Connection between the probe and the level control is realized through a single-pole flexible cable (not supplied).
Electrode probe is not supplied as well.

ACCESSORIES
code FAN02020 Stainless steel electrode AISI 303 - 1 m length.
code FAN02022 Stainless steel electrode AISI 303 - 2 m length.

EA21 Ballasted PVC probe with electrode
SUITABLE FOR WELLS, storage tanks and reservoirs FOR IRRIGATIOn.

                                                          Dimensions (mm)
                                                                              160

                                                                                    Ø 25

FEATURES
Operation at atmospheric pressure.
Maximum temperature: 50°C.
6m cable length included.
Stainless steel electrode AISI 316
(included).

INSTALLATION
Connection between the probe and the level control is realized through a single-pole flexible cable (6 m).

Technical Documents

(1)

Technical Document 1

PDF Document

Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.

Talk to an engineer

Ask a question

Fantini Cosmi Products

3G Electric (S) Pte. Ltd. — Singapore

Product Description

Frequently Asked Questions

Where can I source a Fantini Cosmi EA19 probe in your region?

3G Electric stocks and distributes the Fantini Cosmi EA19 weighted PVC probe. We offer delivery to your location with full logistics and customs clearance handled. Contact us for availability and pricing.

What is the lead time for the Fantini Cosmi EA19 probe?

Lead time varies based on current demand. The EA19 is available to order through 3G Electric. Please request a quote for specific delivery timelines and scheduling to your facility.

What temperature and pressure ratings does the EA19 probe support?

The Fantini Cosmi EA19 features a maximum operating temperature of 160°C and maximum operating pressure of 10 bar. It connects via G 3/8" thread, making it suitable for industrial HVAC and process control applications.
