AllansonUV Ballasts

Allanson UVB80W-120-240V UV Ballast – Program Start

UVB80W-120-240V UV BALLAST – Program Start

SKU 3G-OTH-03051

Brand

Allanson

Item

UVB80W-120-240V UV Ballast – Program Start

Part Number

UVB80W120240V

Local availability & support

Payment: Invoicing in USD. Bank transfer (SWIFT) and corporate PO accepted.

Technical Specifications

Allanson

Manufacturer Part Number

UVB80W120240V

Size

5.0″x3.0″x1.32″

Lamps

1 to 2

Weight

1.1 lb

Lamp mA

425

Lamp Type

Standard

Input Lamps

1 to 2

Lamp Length

12″ to 24″

Potted Case

Yes

Input Voltage

120V-240V

Input Wattage

80

Technical Documents

(1)

Technical Document 1

PDF Document

Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.

Talk to an engineer

Ask a question

Allanson Products

3G Electric (S) Pte. Ltd. — Singapore

Product Description

UVB80W-120-240V UV BALLAST – Program Start

Frequently Asked Questions

What is the Allanson UVB80W-120-240V UV ballast used for?

The Allanson UVB80W-120-240V is a program-start UV ballast designed to power one or two standard UV lamps, such as those used in water treatment, air purification, and industrial disinfection systems. It operates at 120-240V input and delivers 80W at full load, making it suitable for continuous-duty applications.

What are the specifications of the Allanson UVB80W-120-240V UV ballast?

The Allanson UVB80W-120-240V ballast supports 1 to 2 lamps at 425 mA, with input voltage 120-240V ±10%, 50-60 Hz. It has an input power of 80W, power factor >95%, efficiency >90%, and operating frequency >25 kHz. It is UL Listed, Class P, with a potted case and dimensions 5.0"x3.0"x1.32".

Where to buy the Allanson UVB80W-120-240V UV ballast in Singapore?

3G Electric supplies the Allanson UVB80W-120-240V UV ballast to customers in Singapore. We handle logistics, customs clearance, and delivery to your facility. Contact us for pricing and lead time on this program-start ballast, which is compatible with standard UV lamps from brands like Philips and Heraeus.

How to select the right UV ballast for my system?

To select the right UV ballast, match the ballast's lamp current (mA) and lamp type to your UV lamp's requirements. The Allanson UVB80W-120-240V is a program-start ballast rated for 425 mA and standard lamps. Verify input voltage (120-240V) and ensure the ballast's wattage (80W) supports your lamp count. Consult the lamp manufacturer's datasheet for compatibility.
