AllansonUV Ballasts

Allanson UVB324T6-2100-24VDC UV Ballast – Program Start

3G-OTH-03036 UV BALLASTS – Program Start

SKU 3G-OTH-03036

Also listed as: UVB324T6210024VDC · UVB324T6 2100 24VDC

Brand

Allanson

Item

UVB324T6-2100-24VDC UV Ballast – Program Start

Part Number

UVB324T6-2100-24VDC

Local availability & support

Delivery: Worldwide DHL shipping from Singapore; 7–14 business days door-to-door for most destinations.
Payment: Invoicing in USD. Bank transfer (SWIFT) and corporate PO accepted.

Technical Specifications

Allanson

Manufacturer Part Number

UVB324T6210024VDC

Size

14"x3.6"x1.85"

Lamps

3

Weight

10.0 lb

Lamp mA

2100

Lamp Type

Amalgam

Input Lamps

3

Lamp Length

14" to 24"

Potted Case

PC Board

Input Voltage

24V

Input Wattage

360

Technical Documents

(1)

Technical Document 1

PDF Document

Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.

Talk to an engineer

Ask a question

Allanson Products

3G Electric (S) Pte. Ltd. — Singapore

Product Description

3G-OTH-03036 UV BALLASTS – Program Start

Frequently Asked Questions

What is the Allanson 3G-OTH-03036 UV ballast used for?

The Allanson 3G-OTH-03036 is a program-start UV ballast designed to power three amalgam UV lamps. It is commonly used in water treatment, air purification, and industrial disinfection systems where reliable, high-output UV lamp operation is required.

What are the specifications of the Allanson 3G-OTH-03036?

This Allanson ballast operates on 24 VDC input, draws 15.0 A, and delivers 360 W. It drives three amalgam lamps at 2100 mA, with an operating frequency above 30 kHz and efficiency over 90%. It measures 14" x 3.6" x 1.85" and weighs 10.0 lb.

Where to buy the Allanson 3G-OTH-03036 in Singapore?

3G Electric supplies the Allanson 3G-OTH-03036 UV ballast to customers in Singapore. We handle logistics, customs clearance, and delivery to your facility. Contact us for pricing and lead time on this program-start ballast for amalgam lamps.

How to install the Allanson 3G-OTH-03036 ballast?

Installation should follow the wiring diagram provided by Allanson. Ensure the 24 VDC supply is within ±10% and the ballast is mounted in a clean, dry area with ambient temperature between 0–40 °C. Use proper strain relief on lamp leads and verify all connections before powering on.

Used in

Common applications for Allanson

Industrial gas combustion — Allanson 1196-H ferromagnetic ignition transformer for constant-duty spark generation in commercial and industrial gas burners.

Carlin oil burner retrofit — Allanson 2730-630 ignition transformer for Carlin 99, 100, 101, and Card Miser burners, operating at 110V/50Hz.

Gordon Piatt burner service — Allanson 542-GP ignition transformer with 1/4-20 stud terminal for reliable ignition in Gordon Piatt gas burners.

PVI Industries oil heating — Allanson 421-663 double-pole transformer for oil-fired PVI Industries boilers, providing mid-point grounded ignition.

Commercial kitchen ventilation — Allanson DCC2C32700-120-277V LED power supply for dimmable hood lamp lighting in commercial kitchen exhaust systems.

Process heating systems — Allanson 1092-IC ignition transformer for industrial combustion applications requiring 25/20mA output and Rajah connector.
