ELVSolenoid Valves

ELV Stainless steel solenoid valve D.1" NF 230V MINI 0

ELV stainless steel solenoid valve with 1 inch port, rated to 16 bar, operates on 230V at 33 VA. Direct-acting design handles air, water, and oil to 20 CST viscosity, ideal for pneumatic and hydraulic control systems.

SKU 3G-CBM-03244

Also listed as: ELV 25010 · ELV-25010

Brand

ELV

Item

Stainless steel solenoid valve D.1" NF 230V MINI 0

Local availability & support

Delivery: Worldwide DHL shipping from Singapore; 7–14 business days door-to-door for most destinations.
Payment: Invoicing in USD. Bank transfer (SWIFT) and corporate PO accepted.

Technical Specifications

ELV

action

Direct acting, zero differential pressure

connection

1"

valve size

1 inch

maximum pressure

16 bar

voltage option 1

220V, 33 VA

voltage option 2

24V, 32 W

compatible fluids

Air, Water, Oil

fluid viscosity max

20 CST

operating pressure air

0-10 bar

operating pressure oil

0-5 bar

operating pressure water

0-10 bar

Datasheet Content

=v

Solenocia valve

Electrovannes inox NF Code
Action directe - Pression différentiel 0

lectrovanne 1/4” * Avec connecteur ELV25003
lectrovanne 3/8” Avec connecteur ELV25004
lectrovanne 1/2” © Avec connecteur ELV25006
lectrovanne 3/4” © Avec connecteur ELV25008
lectrovanne 1” * Avec connecteur 3G-CBM-03244
lectrovanne 1”1/4 * Avec connecteur ELV25012

lectrovanne 11/2 © Avec connecteur ELV25014

lectrovanne 2” Avec connecteur ELV25016

CARACTERISTIQUES TECHNIQUES

Diamétre Raccord 1/4" 3/8" 1/2" 3/4" 1" W1/41"1/2 2"
Diamétre passage 3mm 16mm 16mm 20mm 25mm 35mm 40mm 50mm
Pression différentielle max. 13 10 10 10 10 10 10 10
Valeur CV 0.23 48 48 7.6 12 24 29 48
Consommation VA 220 volt 22 33 33 33 33 70 70 70
Consommation W 24 volt 13 32 32 32 32 40 40 40
Dim L mm 40.5 69 69 73 99 123 123 168
Dim H mm 75 117 117 123.5 134,5 172 172 209
Viscosité fluide Moins de 20 CST
Fluide Air - Eau - Fioul
T Pression fonctionnement Eau:0~10 Air:0~10  Fioul: 0 ~ 5 bar
| Pression maxi 16 bar
| Température maxi -5 ~90°C
fo = Tension +/- 10% - AC230V
Matériel corps Acier INOX
Membrane NBR
Mode opération Action directe
——_— Type Normalement fermée
Protection IP IP65

PIECES DE RECHANGES POUR VANNES

Modéle | 125003 Jew25004 J ewv25006 | ew25008 | ew2sor0 J ewvasor2 J ewvasor4 J ew25016

Référence bobine 220 V ElV80504 ELV80502 ELV80502 ELV80502 ELV80502 ELV80506 ELV80506 ELV80506
Référence bobine 110 V E1V80522 E1V80520 ElV80520 EV80520 ELV80520 ELV80524 ELV80524 ELV80524
Référence bobine AC 48 V Elv80542 ELV80540 EIV80540 ELV80540 ELV80540 : :

Référence bobine AC 24 V FLV80562 EIV80560 ELV80560 ELV80560 ELV80560 ELV80564 ELV80564 ELV80564
Référence bobine AC 12 V ElV80604 ELV80602 ELV80602 ELV80602 ELV80602 : - -
Référence bobine DC 24 V EV81504 ELV81502 EIV81502 ELV81502 ELV81502 ELV81506 ELV81506 ELV81506
Référence bobine DC 12 V ElV81522 ElV81520 EIV81520 ELV81520 ELV81520 ElV81524 ELV81524 ElV81524
Référence membrane NBR : FlV90502 EIV90502 ELV90502 ELV90504 ELV90506 ELV90507 ELV90508
Référence membrane EPDM - EIV91502 ELV91502 ELV91502 ELV91504 ELV91506 ELV91507 ELV91508
Référence membrane VITON > FlV92502 ELV92502 ELV92502 ELV92504 ELV92506 ELV92507 ELV92508

Technical Documents

(1)

Technical Document 1

PDF Document

Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.

Talk to an engineer

Ask a question

ELV Products

3G Electric (S) Pte. Ltd. — Singapore

Product Description

Frequently Asked Questions

Where can I buy the ELV 25010 solenoid valve in your region?

3G Electric supplies the ELV 25010 stainless steel solenoid valve with delivery to your location. We handle all customs documentation, USD invoicing, and logistics. Contact us for lead time and quotation.

What is the lead time and delivery timeframe for the ELV 25010?

Lead time varies based on current stock status and import schedules. Contact 3G Electric for a specific lead-time quote. We manage all customs clearance and arrange delivery to your location.

What fluids and pressure ranges does the ELV 25010 handle?

The ELV 25010 operates on air (0–10 bar), water (0–10 bar), and oil up to 20 CST viscosity (0–5 bar). Maximum rated pressure is 16 bar. The direct-acting, zero-differential design suits pneumatic and hydraulic control systems.

Used in

Common applications for ELV

Pneumatic automation and directional control — ELV 2/2-way and 3/2-way pilot-operated solenoid valves in compressed-air circuits

Fluid-power machinery — ELV cavity cartridges and manifold-integrated solenoids in hydraulic and lubrication systems

Packaging and filling equipment — ELV proportional and on-off solenoid valves for rapid actuation and media switching

Water treatment and circulation systems — ELV valves rated for continuous water flow control and process isolation

Gas burner and combustion control — ELV solenoid coils for gas isolation and pilot fuel regulation in industrial burner systems

Maintenance and retrofit projects — ELV replacement solenoid coils and membrane kits for in-service valve replacement without removing the valve body
