Dwyer Wall temperature probe TE-END-B

Dwyer wall temperature probe with 10K Ω Type II Thermistor sensor for HVAC and building automation systems. Operating range spans -40 to 60°C. ABS plastic housing suits indoor wall mounting applications.

SKU 3G-CBM-02262

Also listed as: DWY 40016 · DWY-40016

Brand

Dwyer

Item

Wall temperature probe TE-END-B

Local availability & support

Delivery: Worldwide DHL shipping from Singapore; 7–14 business days door-to-door for most destinations.
Payment: Invoicing in USD. Bank transfer (SWIFT) and corporate PO accepted.

Technical Specifications

Dwyer

sensor type

10K Ω Type II Thermistor

housing material

ABS plastic

operating temperature max celsius

60

operating temperature min celsius

-40

Datasheet Content

Série
    TE-N/E            Sonde de température à fixation murale
                      Boîtier Discret à Fixation Murale


                                                                                                                            1-1/16
                                                                                                                            [27.05]               1-3/16                 1-5/32
                                                                                                                                                  [30.00]                [29.39]

                                                                                                                                                                                3X-5/32
                                                                                                                                      21/64                                      [3.87]
                                                                                                3-21/32
                                                                                                [92.96]                               [8.38]

                                                                                                                                               3X-3/8
                                                                                                                                               [9.36]
                                                                                                              3-9/16
                                                                                                              [90.42]
                                                                                                                               1-3/32                        35/64
                                                                                                                               [27.69]                      [14.02]


                                                                                                                                         2X-11/64
                                                                                                                                          [4.47]                      3-1/64
                                                                                                     4-1/2
                                                                                                   [114.30]                                                           [76.56]



                                                                                                                2-51/64                    31/64
                   Européen                                  Nord Américain                                     [71.12]                   [12.32]




La Série TE-N/E Sonde de Température à Fixation Murale fournit une                                SPÉCIFICATIONS
température d’entrée à faible coût pour tout système de gestion technique du bâtiment. De         Précision :
larges fentes dans le boîtier permettent d’obtenir un flux d’air correct ; la sonde mesure        Thermostat temp. de la sonde : ±0.2°C @ 25°C ;
précisément la température ambiante dans les chambres d’hôtels ou bâtiments de bureaux.           RTD temp. de la sonde : DIN classe B; ±0.3°C @ 0°C.
Plusieurs trous de fixation sur la plaque murale permettent le montage sur diverses surfaces.     Température Opérationnelle : de -40 à +60°C.
                                                                                                  Matériau du Boîtier : plastique ABS.
                                                                                                  Poids : 136 g.
 Modèle           Type de Sonde                                                   Réf.
 TE-NND-A         10K Ω Type III Thermistor Version N.A.                       DWY40002           Résistance vs tableau de Température
                                                                                                  Voir page 31.
 TE-NND-B         10K Ω Type II Thermistor Version N.A.                        DWY40004
 TE-NND-C         3K Ω Thermistor Version N.A.                                 DWY40006
 TE-NND-D         Pt100 Ω RTD Version N.A.                                     DWY40008
 TE-NND-E         Pt1000 Ω RTD Version N.A.                                    DWY40010
 TE-NND-F         20K Ω Thermistor Version N.A.                                DWY40012
 TE-END-A         10K Ω Type III Thermistor Version E.U.                       DWY40014
 TE-END-B         10K Ω Type II Thermistor Version E.U.                        3G-CBM-02262
 TE-END-C         3K Ω Thermistor Version E.U.                                 DWY40018
 TE-END-D         Pt100 Ω RTD Version E.U.                                     DWY40020
 TE-END-E         Pt1000 Ω RTD Version E.U.                                    DWY40022
 TE-END-F         20K Ω Thermistor Version E.U.                                DWY40024
