Dwyer Wall temperature probe TE-END-A

Dwyer wall temperature probe TE-END-A is a thermistor-based sensor for HVAC and building automation applications. Features a 10K Ω thermistor element and ABS plastic housing rated for -40 to +60°C operation, ideal…

SKU 3G-CBM-02261

Also listed as: DWY 40014 · DWY-40014

Brand

Dwyer

Item

Wall temperature probe TE-END-A

Local availability & support

Delivery: Worldwide DHL shipping from Singapore; 7–14 business days door-to-door for most destinations.
Payment: Invoicing in USD. Bank transfer (SWIFT) and corporate PO accepted.

Technical Specifications

Dwyer

sensor type

10K Ω Thermistor

housing material

ABS plastic

operating temperature

-40 to +60°C

Datasheet Content

Série
    TE-N/E            Sonde de température à fixation murale
                      Boîtier Discret à Fixation Murale


                                                                                                                            1-1/16
                                                                                                                            [27.05]               1-3/16                 1-5/32
                                                                                                                                                  [30.00]                [29.39]

                                                                                                                                                                                3X-5/32
                                                                                                                                      21/64                                      [3.87]
                                                                                                3-21/32
                                                                                                [92.96]                               [8.38]

                                                                                                                                               3X-3/8
                                                                                                                                               [9.36]
                                                                                                              3-9/16
                                                                                                              [90.42]
                                                                                                                               1-3/32                        35/64
                                                                                                                               [27.69]                      [14.02]


                                                                                                                                         2X-11/64
                                                                                                                                          [4.47]                      3-1/64
                                                                                                     4-1/2
                                                                                                   [114.30]                                                           [76.56]



                                                                                                                2-51/64                    31/64
                   Européen                                  Nord Américain                                     [71.12]                   [12.32]




La Série TE-N/E Sonde de Température à Fixation Murale fournit une                                SPÉCIFICATIONS
température d’entrée à faible coût pour tout système de gestion technique du bâtiment. De         Précision :
larges fentes dans le boîtier permettent d’obtenir un flux d’air correct ; la sonde mesure        Thermostat temp. de la sonde : ±0.2°C @ 25°C ;
précisément la température ambiante dans les chambres d’hôtels ou bâtiments de bureaux.           RTD temp. de la sonde : DIN classe B; ±0.3°C @ 0°C.
Plusieurs trous de fixation sur la plaque murale permettent le montage sur diverses surfaces.     Température Opérationnelle : de -40 à +60°C.
                                                                                                  Matériau du Boîtier : plastique ABS.
                                                                                                  Poids : 136 g.
 Modèle           Type de Sonde                                                   Réf.
 TE-NND-A         10K Ω Type III Thermistor Version N.A.                       DWY40002           Résistance vs tableau de Température
                                                                                                  Voir page 31.
 TE-NND-B         10K Ω Type II Thermistor Version N.A.                        DWY40004
 TE-NND-C         3K Ω Thermistor Version N.A.                                 DWY40006
 TE-NND-D         Pt100 Ω RTD Version N.A.                                     DWY40008
 TE-NND-E         Pt1000 Ω RTD Version N.A.                                    DWY40010
 TE-NND-F         20K Ω Thermistor Version N.A.                                DWY40012
 TE-END-A         10K Ω Type III Thermistor Version E.U.                       3G-CBM-02261
 TE-END-B         10K Ω Type II Thermistor Version E.U.                        DWY40016
 TE-END-C         3K Ω Thermistor Version E.U.                                 DWY40018
 TE-END-D         Pt100 Ω RTD Version E.U.                                     DWY40020
 TE-END-E         Pt1000 Ω RTD Version E.U.                                    DWY40022
 TE-END-F         20K Ω Thermistor Version E.U.                                DWY40024

Technical Documents

(1)

Technical Document 1

PDF Document

Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.

Talk to an engineer

Ask a question

Dwyer Products

3G Electric (S) Pte. Ltd. — Singapore

Product Description

Frequently Asked Questions

Where can I buy the Dwyer TE-END-A wall temperature probe worldwide?

3G Electric is an authorized Dwyer distributor offering worldwide delivery. We handle logistics, customs clearance, and procurement documentation. Contact us for pricing and lead times on the TE-END-A (part DWY40014).

What is the operating temperature range of the Dwyer TE-END-A?

The TE-END-A operates reliably between -40°C and +60°C, making it suitable for indoor HVAC and building automation applications across diverse climate zones.

What sensor type does the Dwyer TE-END-A use?

The probe features a 10K Ω thermistor element housed in durable ABS plastic, providing accurate temperature measurement for climate control and automated building systems.
