Dwyer Magnehelic pressure gauge 2300-120Pa

Dwyer Magnehelic differential pressure gauge measures low-range pressure differentials from 0–120 Pa, ideal for HVAC, clean room, and filter monitoring applications. The Series 2000 design provides reliable…

SKU 3G-CBM-02115

Also listed as: DWY 01608 · DWY-01608

Brand

Dwyer

Item

Magnehelic pressure gauge 2300-120Pa

Local availability & support

Delivery: Worldwide DHL shipping from Singapore; 7–14 business days door-to-door for most destinations.
Payment: Invoicing in USD. Bank transfer (SWIFT) and corporate PO accepted.

Technical Specifications

Dwyer

type

magnehelic differential pressure gauge

series

2000

pressure range

0-120 Pa

Datasheet Content

DECLARATION OF CONFORMITY
We,
                                                             Dwyer Instruments, Inc.
                                                            102 Indiana Highway 212
                                                           Michigan City, IN 46360 USA
                                                                 +1-219-879-8868

declare under our sole responsibility our Series 2000 Differential Pressure Gauge to which this declaration relates is in conformity with the
following EU Directives and harmonized Standards:

Directive 2014/68/EU Pressure Equipment (PED) Article 4 Paragraph 3 Sound Engineering Practice (Pressure Accessory for Fluid Group 2)

A CE Mark is neither required nor permitted for this classification.

The authorized representative located within the Community is:

Comhas Srl
Via Matteotti 66
200092 Cinisello Balsamo
Milano, Italy
+39 335.7064538

On behalf of Dwyer Instruments, Inc.,



Doug McCall
Senior Regulatory Engineer
July 21, 2020
Michigan City, Indiana, USA




                                                                       Page 1 of 1

Technical Documents

(1)

Technical Document 1

PDF Document

Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.

Talk to an engineer

Ask a question

Dwyer Products

3G Electric (S) Pte. Ltd. — Singapore

Product Description

Frequently Asked Questions

Where can I buy the Dwyer 2300-120Pa Magnehelic gauge worldwide?

Order from 3G Electric, an authorized distributor. We source and deliver the Dwyer 2300-120Pa globally. Lead time and shipping details are available on request—contact our team for a quote.

What is the pressure range of the Dwyer 2300-120Pa?

The Dwyer Series 2000 Magnehelic gauge measures differential pressures from 0–120 Pa. It is ideal for low-range HVAC, clean room, and filter monitoring applications requiring precise airflow control.

What applications is the Dwyer 2300-120Pa suited for?

The Dwyer 2300-120Pa is designed for HVAC systems, clean room monitoring, and filter differential pressure indication. The Series 2000 design provides reliable, accurate measurement for ventilation and airflow control systems.

Used in

Common applications for Dwyer

Combustion air-filter monitoring — Magnehelic Series 2000 on burner air-intake filter banks

Clean-room and pharmaceutical pressurisation — Magnehelic / Capsuhelic differential-pressure gauges

HVAC fan-discharge static pressure — Mark II inclined-vertical manometers on AHU test points

Filter-blockage alarms — Photohelic Series 3000 combined gauge/switch on air-handling units

BMS-integrated pressure monitoring — Digihelic DH3 with 4–20 mA output for building management
