Dwyer Magnehelic pressure gauge 2300-60 Pa

Dwyer Magnehelic pressure gauge measures differential pressure from 0–60 Pa with a 101.6 mm dial, operating across –6.67 to 60 °C. Ideal for HVAC, cleanroom, and low-pressure industrial applications requiring precise…

SKU 3G-CBM-02114

Also listed as: DWY 01602 · DWY-01602

Brand

Dwyer

Item

Magnehelic pressure gauge 2300-60 Pa

Local availability & support

Delivery: Worldwide DHL shipping from Singapore; 7–14 business days door-to-door for most destinations.
Payment: Invoicing in USD. Bank transfer (SWIFT) and corporate PO accepted.

Technical Specifications

Dwyer

range pa

0-60

dial diameter mm

101.6

temperature limits c

-6.67 to 60

Datasheet Content

DECLARATION OF CONFORMITY
We,
                                                             Dwyer Instruments, Inc.
                                                            102 Indiana Highway 212
                                                           Michigan City, IN 46360 USA
                                                                 +1-219-879-8868

declare under our sole responsibility our Series 2000 Differential Pressure Gauge to which this declaration relates is in conformity with the
following EU Directives and harmonized Standards:

Directive 2014/68/EU Pressure Equipment (PED) Article 4 Paragraph 3 Sound Engineering Practice (Pressure Accessory for Fluid Group 2)

A CE Mark is neither required nor permitted for this classification.

The authorized representative located within the Community is:

Comhas Srl
Via Matteotti 66
200092 Cinisello Balsamo
Milano, Italy
+39 335.7064538

On behalf of Dwyer Instruments, Inc.,



Doug McCall
Senior Regulatory Engineer
July 21, 2020
Michigan City, Indiana, USA




                                                                       Page 1 of 1

Technical Documents

(1)

Technical Document 1

PDF Document

Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.

Talk to an engineer

Ask a question

Dwyer Products

3G Electric (S) Pte. Ltd. — Singapore

Product Description

Frequently Asked Questions

Where can I buy the Dwyer Magnehelic 2300-60 pressure gauge worldwide?

Order the Dwyer Magnehelic 2300-60 from 3G Electric. We are an authorised distributor handling worldwide delivery, customs clearance, and logistics. Lead times available on request—contact us for a formal quote.

What is the measurement range and dial size of the Dwyer 2300-60?

The Dwyer Magnehelic 2300-60 measures differential pressure from 0–60 Pa with a 101.6 mm dial diameter. Operating temperature range is –6.67 to 60 °C, suitable for HVAC, cleanroom, and low-pressure industrial applications.

Is the Dwyer Magnehelic 2300-60 suitable for cleanroom environments?

Yes. The Dwyer Magnehelic 2300-60 is designed for cleanroom and low-pressure industrial applications requiring precise differential pressure monitoring. Its 0–60 Pa range and sealed construction make it ideal for HVAC ductwork and clean-space pressure verification.

Used in

Common applications for Dwyer

Combustion air-filter monitoring — Magnehelic Series 2000 on burner air-intake filter banks

Clean-room and pharmaceutical pressurisation — Magnehelic / Capsuhelic differential-pressure gauges

HVAC fan-discharge static pressure — Mark II inclined-vertical manometers on AHU test points

Filter-blockage alarms — Photohelic Series 3000 combined gauge/switch on air-handling units

BMS-integrated pressure monitoring — Digihelic DH3 with 4–20 mA output for building management
