CBM Pump SI-83 (replaces SI-82)

CBM SI-83 is a centrifugal pump with integrated tank for air conditioning condensate removal, featuring 2 L tank capacity and maximum flow rate of 700 L/h. Handles condensate temperatures to 55°C (80°C…

SKU 3G-CBM-01112

Also listed as: CLI 50006 · CLI-50006

Brand

CBM

Item

Pump SI-83

Local availability & support

Delivery: Worldwide DHL shipping from Singapore; 7–14 business days door-to-door for most destinations.
Payment: Invoicing in USD. Bank transfer (SWIFT) and corporate PO accepted.

Technical Specifications

CBM

type

centrifugal_pump_with_tank

model

SI-83

tank capacity l

2

hose diameter mm

6

max flow rate l h

700

min condensate pH

2.5

power cord length m

1.8

max condensate temperature

55°C (80°C short periods)

safety switch cord length m

1

Datasheet Content

Si-83                    EN
                                                 FR
                                                  IT
                                                 ES
                                                 DE
                                                 NL
                                                 RU

N957/00 Edition 20/06

N957-00_2006.indd 1             07/02/2020 14:27:54
          Fig. 1
                                                                                                                                  B
                                                                                                                                 ACC00939
                                                                                          A ACC00911                             Ø 15/17 - 20 - 24/25 - 32 - 40 mm
                                                                                              Ø 10 mm int - 25 m                 Ø int 5/8’’- 3/4’’- 1’’- 1 1/4’’ - 1 1/2’’
                                                                                              Ø int 3/8’’- 82’

                                                                                                                                                                               F
                                                                                                 C                                                   E
                                                                                                ACC00908                  Ø 10 - 10 mm               6 mm (1/4’’)
                                                                                                Ø 10 - 20 mm        D
                                                                                                                          Ø 3/8’’ - 3/8’’
                                                                                                Ø 3/8’’ - 3/4’’
                                                                                                                                                                              PH0100SIUN23

                     SI83CE01UN23 - SI83CE41UN23 - SI83CE71UN23 -                                                             SI83UL02UN12 - SI83UL42UN12 - SI83UL72UN12 -
                     SI83CE04UN23 - SI83CE74UN23 : E                                                                          SI83UL02UN23 - SI83UL42UN23 - SI83UL72UN23 : B
                     SI83CE02UN23 - SI83CE42UN23 : A, B                                                                       SI83UL03UN12 - SI83UL03UN23 : A, B
                     SI83CE43UN23 : A, B, F
                     SI83CE05UN23 : A, C, D

            Fig. 2                                                                                                                    App.

                                                                                                                                            Si-83 mobile App

            Fig. 3                                                          SI83CE01UN23 - SI83CE41UN23 - SI83CE71UN23 - SI83CE02UN23 - SI83CE42UN23 -
                                                                            SI83CE43UN23 - SI83CE04UN23 - SI83CE74UN23 - SI83CE05UN23

                            Discharge head - Hauteur de refoulement - Altezza di

                            mandata - Altura de descarga - Förderhöhe - Altura de

                            descarga - Niveau opvoerhoogte (m)

                                                                                    Flow rate - Portata - Caudal - Fördermenge - Caudal - Hoeveelheid (l/h)

     Google Play and the Google Play logo are trademarks of Google LLC.

 2
     App Store is a service mark of Apple Inc.

N957-00_2006.indd 2                                                                                                                                                             07/02/2020 14:27:56
            Fig. 3 bis
                                                    120 V: SI83UL03UN12 - SI83UL02UN12 -                                              230 V: SI83UL03UN23 - SI83UL02UN23 -
                                                    SI83UL42UN12 - SI83UL72UN12                                                       SI83UL42UN23 - SI83UL72UN23

      Discharge head - Altura de descarga (ft)                                             Discharge head - Altura de descarga (ft)

                                                     Flow rate - Caudal (gph)                                                           Flow rate - Caudal (gph)

                                                 Fig. 4

                                                                                                                                      AL *: 48 mm (1 7/8’’)
                                                                                                                                      OFF : 21 mm (0 13/16’’)
                                                                                                                                      ON : 40 mm (1 9/16’’)

                                                 Fig. 5

                                                                                                                                                           pH ≤ 3
                                                                                                                                                           + pH Safe 1,
                                                                                                                                                           ref : PH0100SIUN23

                                                                                                                                                                                               3

N957-00_2006.indd 3                                                                                                                                                             07/02/2020 14:27:56
     Fig. 6

                                                                             Max 15°

                                   > 20 cm                    > 20 cm

     B.
                                                                        C.

              262 mm - 10 5/16’’

                                             M6 max.

       Fig. 7
                                                 B                                     ACC00940
                                               ACC00939

                                                                                           +
                                             Ø 40 mm, 1 1/2’’                          Ø 42-46 mm
         Ø 30 mm                             Ø 32 mm, 1 1/4’’
         Ø 1 3/16 ’’                         Ø 24 - 25 mm, 1’’
                                             Ø 20 mm, 3/4’’
                       IN                    Ø 15 - 17 mm, 5/8’

                                                                        B

 4

N957-00_2006.indd 4                                                                             07/02/2020 14:27:58
        Fig. 8
            A.

                      A                   A
                                                OUT               Ø 10 mm int.
                                                                  Ø 3/8 ’’
                                                                                                    * PLEASE NOTE *
                                                                                                    ALL PIPE CONNECTIONS
                                                                                                    MUST BE SECURED WITH A
                                                                                                    TIE WRAP/METAL CLIP
                                                                                                    (ACC00913)

            B.                                         D        C
             A
                                           A                                            OUT
                               D                                          Ø 20 mm
             C                                                            Ø 3/4 ’’

                                                       Use a tie wrap or metal clip (ACC00913)

       Fig. 9         A.                         ACC00923

                                                                                                                  c << 0°C
                                                                                                                       32°F

                                                             ACC00923
                      B.

                                                                                                            ACC00920

                                          ACC00920
                                                                                                 ACC00920
                               ACC00923                                      ACC00923
                          C.

                                                                                                                c << 0°C
                                                                                                                     32°F

                                                                                                                                5

N957-00_2006.indd 5                                                                                              07/02/2020 14:27:59
       Fig. 10        NO

                      NC

 6

N957-00_2006.indd 6        07/02/2020 14:28:00
      Fig. 10                                                            NC/NO
                                                         (G)

                                                               Pump power
                                                     N

                                                     L

                                           Al (C)
                                           Al (NC)                 Pump
                                           Al (NO)             safety switch

                                                                            Al (NC)   Al (NO)
                                                                            Black     Red

                                                                            Al (C)               Al (C)
                                                                            Grey                 Grey

       Fig. 11
                               T10

    CERTIFICAT DE CONFORMITE / CONFORMITY CERTIFICATE /BEREINSTIMMUNGSBESCHEINIGUNG / CERTIFICATO DI CONFORMITA’

    SAUERMANN - Z.I l’orée de Chevry - 77173 CHEVRY COSSIGNY- FRANCE
    - déclare que le produit pompe de relevage de condensats Si-83 est conforme aux normes :
    - declares that the product Si-83 condensate lift pump is in conformity with the standar :
    - erklärt, dass das Produkt, Kondensatförderpumpe Si-83 den fogenden Normen entspricht :
    - dichiara che il prodotto pompa elevatrice di condensa Si-83 conforme alle norme :
    EN 60335-1
    EN 60335-2-41
    EN 55014-1, EN 55014-2
    EN 61000-3-2, EN 61000-3-3
    EN 62233:2008

                Motor-Operated Water Pumps [UL 778:2016 Ed.6+R:20Oct2017]
                Liquid Pumps [CSA C22.2#108:2014 Ed.5]

    - Nous vous rappelons qu’il est interdit de mettre en service la pompe avant que la machine dans laquelle…

Technical Documents

(2)

Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.

Talk to an engineer

Ask a question

CBM Products

3G Electric (S) Pte. Ltd. — Singapore

Product Description

Frequently Asked Questions

Where can I buy the CBM SI-83 condensate pump worldwide?

3G Electric is an authorised distributor of the CBM SI-83. We source and deliver to facilities globally. Contact us for availability and lead times — logistics and customs are handled in-house.

What is the lead time for the CBM SI-83?

Lead times vary depending on availability and destination. Please request a quote for the CBM SI-83 (part number CLI50006). We arrange worldwide delivery with full logistics support.

What condensate temperatures can the SI-83 handle?

The CBM SI-83 handles continuous condensate temperatures up to 55°C, with intermittent operation to 80°C. Minimum pH is 2.5. It suits standard HVAC and refrigeration condensate removal applications.
