Crydom 3G-OTH-38801 — Technical Specifications

Name: Crydom 3G-OTH-38801 CRYDOM Solid State Relay: Surface Mounted, 12 A Max Output Current, SCR, AC Output (MPN HA4812). Key specifications — Brand: CRYDOM; Current Type: AC; Electrical Connection: Screw Clamp; Finger Safe: No; Input Current: 10 mA; Maximum Output Current without Heat Sink: 10 A; Mounting Style: Panel; Output Voltage: 48 to 530V AC.
Brand: Crydom

The CRYDOM Solid State Relay (SKU 1DTG6, MPN HA4812) is a panel-mounted, AC-output relay with a Form A (SPST-NO) switch configuration. It features a screw-clamp electrical connection, an input current of 10 mA, and an output voltage range of 48 to 530V AC. The relay has a maximum output current of 10 A without a heat sink and is not finger-safe.

View Product & Quote

Technical Specifications

Parameter	Value
Brand	CRYDOM
Finger Safe	No
Current Type	AC
Input Current	10 mA
Mounting Style	Panel
Output Voltage	48 to 530V AC
Switch Configuration	Form A
Voltage/Current Type	AC Output
Electrical Connection	Screw Clamp
Manufacturer Part Number	HA4812
Maximum Output Current Without Heat Sink	10 A
