PUMP W1570 R

Name: PUMP W1570 R
Brand: Pratissoli
SKU: pump-w1570-r-1

On RequestIndustrial Pumps

Price on request — send us an enquiry for current pricing.

PUMP W1570 R

Minimum order: 3 units
Lead time: Worldwide DHL shipping from Singapore; 7–14 business days door-to-door for most destinations.

Technical specifications

power hp	27
power kw	19.85
weight kg	22.3
flow l min	70
flow us gpm	18.5
pressure bar	150
pressure mpa	15
pressure psi	2175
rotation regime rpm	1450
overall dimensions l x l x h mm	345.5

Frequently asked questions

Where can I buy the Pratissoli W1570 R pump worldwide?+

Source the Pratissoli W1570 R through 3G Electric, an authorized distributor. We handle worldwide delivery, customs clearance, and logistics. Lead time on request — contact us for availability and competitive pricing on this 70 L/min, 150 bar unit.

What are the key specifications of the Pratissoli W1570 R?+

The Pratissoli W1570 R delivers 70 L/min (18.5 US gpm) at 150 bar (15 MPa / 2175 psi). Rated continuous power is 19.85 kW (27 hp) at 1450 rpm. Overall dimensions are 345.5 mm length. Weight is 22.3 kg. Designed for compact, high-pressure industrial applications.

What applications suit the Pratissoli W1570 R pump?+

The W1570 R is ideal for high-pressure fluid transfer in manufacturing, processing, and industrial systems requiring 70 L/min at 150 bar. Its compact design and 19.85 kW continuous rating make it suitable for integrated machinery, press systems, and dedicated production lines needing reliable, sustained performance.
