PUMP TS1630 R

Name: PUMP TS1630 R
Brand: Interpump
SKU: pump-ts1630-r

On RequestIndustrial Pumps

Price on request — send us an enquiry for current pricing.

PUMP TS1630 R

Minimum order: 2 units
Lead time: Worldwide DHL shipping from Singapore; 7–14 business days door-to-door for most destinations.

Technical specifications

power hp	12.5
power kw	9.2
weight kg	15
flow l min	30
flow us gpm	7.92
pressure bar	160
pressure mpa	16
pressure psi	2320
rotation regime rpm	1750
overall dimensions l x l x h mm	327

Frequently asked questions

Where can I buy the Interpump TS1630 R pump worldwide?+

Order the Interpump TS1630 R from 3G Electric, an authorised Interpump distributor. We handle logistics, customs clearance, and delivery to manufacturing facilities globally. Lead time on request.

What is the flow rate and pressure rating of the TS1630 R?+

The Interpump TS1630 R delivers 30 L/min (7.92 US gpm) at 160 bar (16 MPa / 2320 psi). Its 9.2 kW motor runs at 1750 rpm, ideal for high-pressure hydraulic applications.

What are the physical dimensions of the TS1630 R pump?+

The Interpump TS1630 R measures 327 mm in overall length, weighs 15 kg, and is designed for compact installation in manufacturing and mobile equipment hydraulic systems requiring space-efficient, high-pressure performance.
