Pratissoli PUMP SN71106 R

The Pratissoli PUMP SN71106 R is a 40.4 kW industrial pump delivering 106 L/min at 200 bar, designed for high-pressure hydraulic applications requiring sustained performance. With 1000 rpm operation and robust…

SKU 3G-ITP-00800

Also listed as: SN71106000 · SN71106 000

Brand

Pratissoli

Item

PUMP SN71106 R

Local availability & support

Delivery: Worldwide DHL shipping from Singapore; 7–14 business days door-to-door for most destinations.
Payment: Invoicing in USD. Bank transfer (SWIFT) and corporate PO accepted.

Technical Specifications

Pratissoli

Flow Rate

106 L/min

Pressure

200 bar

Power

40.4 kW

Speed

1000 RPM

Weight

68 kg

Dimensions

526 mm

Power

55 HP

Flow (US)

28 GPM

Pressure

20 MPa

Pressure

2900 PSI

Datasheet Content

W3025




TECHNICAL INFORMATION
Flow (L/min)                        25
Flow (US Gpm)                       6,60
Rotation regime (rpm)               1450
Pressure (MPa)                      30
Pressure (bar)                      300
Pressure (psi)                      4350
Power (hp)                          20
Power (kW)                          14,70
Overall dimensions L x l x h (mm)   340,5x242,5x189,5
Weight (kg)                         18,5




W3025                                                   3/21/2026   Page 1 - 11
Copyright INTERPUMP GROUP S.P.A
W3025

     Documents

Male shaft (key)

Double male shaft (key)

Male shaft (key) - vers. ATEX




W3025                             3/21/2026   Page 2 - 11
Copyright INTERPUMP GROUP S.P.A
Illustration Male shaft (key)




W3025                             3/21/2026   Page 3 - 11
Copyright INTERPUMP GROUP S.P.A
Illustration Male shaft (key)

Pos.     Code           Description                    Qty Notes
KIT3     34000301       KIT 3 OIL SEAL D.30X55X7       1
KIT2     34000201       KIT 2 OIL SEAL D. 22X32X5,5    1

KIT171   34017101       KIT 171 COMPL.SEAL D.20 (66)   1

KIT170   34017001       KIT 170 PACKING D.20 (66)      1

KIT169   34016901       KIT 169 INTAKE/DEL.VALVE (66) 1


51       98204300       PLUG G1/4X10                   3
50       98226800       PLUG G3/4X16                   1
49       96770000       WASHER 26,5X32X1,5             1
48       96738000       WASHER 17,5X23X1,5             1
47       90162500       OIL SEAL 22x32x5               3
46       90912600       BUSHING 22X25X30               3
45       99364400       SCREW M 10x18-5931             4
44       96710600       WASHER 10,2                    4
43       47200074       PUMP FOOT                      2
42       90269200       PACKING D.20X30X10 HP (66)     3


41       66216070       INTERMEDIATE RING D.20         3
40       90269000       PACKING D.20X28X6.5 LP (66)    3


39       90361600       O-RING 34,65X1,78 (2137)       3
38       66080070       PACKING RETAINER D. 20         3
37       98210000       PLUG G3/8X13                   1
36       90164800       OIL SEAL 30x55x7               1
35       47151022       OPEN SIDE COVER (47-66)        1
34       66219566       PISTON BOLT                    3
33       90358400       O-RING D.10,82X1,78(2043)90SH 3


32       66040009       PISTON D. 20X54                3
31       96710100       WASHER D. 10X28X0.5            3
30       66050066       PISTON GUIDE - S.S.            3
29       97740500       CONNECTING ROD-PIN D.14X39 3


28       99309900       SCREW M 8x35 UNI 5931          6
27       90358500       O-RING 10,82X1,78 (2043)       4
26       98204250       PLUG G1/4"x12                  1
25       99188400       SCREW M 6x20 UNI 5931          4
24       66160022       REAR COVER                     1
23       90392200       O-RING D.133.02X 2,62(3525)    1


22       66030001       CONNECTING ROD                 3
21       91489200       KEY 8(h9)X7X35 UNI 6604/A      1




W3025                                                              3/21/2026   Page 4 - 11
Copyright INTERPUMP GROUP S.P.A
Illustration Male shaft (key)

Pos.   Code             Description                 Qty Notes

20     66020035         CRANKSHAFT C.19 - D. 24     1
19     98210600         OIL DIP-STICK G3/8X80       1
18     66010022         CRANKCASE                   1
17     91838000         ROLLER BEARING NJ2206EC     2
16     90075600         CIRCLIP D.45 (ZJ45)         1
15     70211801         OIL SIGHT GLASS             1
14     90387700         O-RING 39,34X2,62 (3156)    1
13     90391300         O-RING 67,95X2,62 (3268)    2
12     47151222         SIDE CRANKCASE COVER FOR    1
                        OIL GAUGE
11     99303900         SCREW M 8x16 UNI 5931       8
10     36712701         INTAKE/DEL.VALVE ASSY(66)   6


9      66130041         VALVE CAP M32x1.5x29.5      6
8      90516500         ANTI-EXTR.RING D.24.7x29x1.5 6


7      36203551         VALVE CAGE                  6
6      94738800         SPRING Dm. 10x18.5          6
5      36203476         SPHERICAL VALVE             6
4      36203366         VALVE SEAT                  6
3      90385700         O-RING 23,81X2,62 (132)     12
2      99380100         SCREW M10X90 UNI 5931 8.8   8


1      66120041         PUMP HEAD (PISTON D.20)     1




W3025                                                           3/21/2026   Page 5 - 11
Copyright INTERPUMP GROUP S.P.A
Illustration Double male shaft (key)




W3025                                  3/21/2026   Page 6 - 11
Copyright INTERPUMP GROUP S.P.A
Illustration Double male shaft (key)

Pos.     Code           Description                    Qty Notes
KIT3     34000301       KIT 3 OIL SEAL D.30X55X7       1
KIT2     34000201       KIT 2 OIL SEAL D. 22X32X5,5    1

KIT171   34017101       KIT 171 COMPL.SEAL D.20 (66)   1

KIT170   34017001       KIT 170 PACKING D.20 (66)      1

KIT169   34016901       KIT 169 INTAKE/DEL.VALVE (66) 1


51       98204300       PLUG G1/4X10                   3
50       98226800       PLUG G3/4X16                   1
49       96770000       WASHER 26,5X32X1,5             1
48       96738000       WASHER 17,5X23X1,5             1
47       90162500       OIL SEAL 22x32x5               3
46       90912600       BUSHING 22X25X30               3
45       99364400       SCREW M 10x18-5931             4
44       96710600       WASHER 10,2                    4
43       47200074       PUMP FOOT                      2
42       90269200       PACKING D.20X30X10 HP (66)     3


41       66216070       INTERMEDIATE RING D.20         3
40       90269000       PACKING D.20X28X6.5 LP (66)    3


39       90361600       O-RING 34,65X1,78 (2137)       3
38       66080070       PACKING RETAINER D. 20         3
37       98210000       PLUG G3/8X13                   1
36       90164800       OIL SEAL 30x55x7               2
35       47151022       OPEN SIDE COVER (47-66)        2
34       66219566       PISTON BOLT                    3
33       90358400       O-RING D.10,82X1,78(2043)90SH 3


32       66040009       PISTON D. 20X54                3
31       96710100       WASHER D. 10X28X0.5            3
30       66050066       PISTON GUIDE - S.S.            3
29       97740500       CONNECTING ROD-PIN D.14X39 3


28       99309900       SCREW M 8x35 UNI 5931          6
27       90358500       O-RING 10,82X1,78 (2043)       4
26       98204250       PLUG G1/4"x12                  1
25       99188400       SCREW M 6x20 UNI 5931          4
24       66160022       REAR COVER                     1
23       90392200       O-RING D.133.02X 2,62(3525)    1


22       66030001       CONNECTING ROD                 3
21       91489200       KEY 8(h9)X7X35 UNI 6604/A      2




W3025                                                              3/21/2026   Page 7 - 11
Copyright INTERPUMP GROUP S.P.A
Illustration Double male shaft (key)

Pos.   Code             Description                  Qty Notes

20     66021035         CRANKSHAFT C.19 - DUAL PTO   1


19     98210600         OIL DIP-STICK G3/8X80        1
18     66010022         CRANKCASE                    1
17     91838000         ROLLER BEARING NJ2206EC      2
13     90391300         O-RING 67,95X2,62 (3268)     2
11     99303900         SCREW M 8x16 UNI 5931        8
10     36712701         INTAKE/DEL.VALVE ASSY(66)    6


9      66130041         VALVE CAP M32x1.5x29.5       6
8      90516500         ANTI-EXTR.RING D.24.7x29x1.5 6


7      36203551         VALVE CAGE                   6
6      94738800         SPRING Dm. 10x18.5           6
5      36203476         SPHERICAL VALVE              6
4      36203366         VALVE SEAT                   6
3      90385700         O-RING 23,81X2,62 (132)      12
2      99380100         SCREW M10X90 UNI 5931 8.8    8


1      66120041         PUMP HEAD (PISTON D.20)      1




W3025                                                            3/21/2026   Page 8 - 11
Copyright INTERPUMP GROUP S.P.A
Illustration Male shaft (key) - vers. ATEX




W3025                                        3/21/2026   Page 9 - 11
Copyright INTERPUMP GROUP S.P.A
Illustration Male shaft (key) - vers. ATEX

Pos.     Code           Description                    Qty Notes
KIT3     34000301       KIT 3 OIL SEAL D.30X55X7       1
KIT2     34000201       KIT 2 OIL SEAL D. 22X32X5,5    1

KIT171   34017101       KIT 171 COMPL.SEAL D.20 (66)   1

KIT170   34017001       KIT 170 PACKING D.20 (66)      1

KIT169   34016901       KIT 169 INTAKE/DEL.VALVE (66) 1


53       99180900       SCREW M06X10 5931 A2-70        1
52       96693950       WASHER 6.4x11.0x0.7 D6798A     1
                        INOX
51       98204300       PLUG G1/4X10                   3
50       98226800       PLUG G3/4X16                   1
49       96770000       WASHER 26,5X32X1,5             1
48       96738000       WASHER 17,5X23X1,5             1
47       90162500       OIL SEAL 22x32x5               3
46       90912600       BUSHING 22X25X30               3
45       99364400       SCREW M 10x18-5931             4
44       96710600       WASHER 10,2                    4
43       47200074       PUMP FOOT                      2
42       90269200       PACKING D.20X30X10 HP (66)     3


41       66216070       INTERMEDIATE RING D.20         3
40       90269000       PACKING D.20X28X6.5 LP (66)    3


39       90361600       O-RING 34,65X1,78 (2137)       3
38       66080070       PACKING RETAINER D. 20         3
37       98210000       PLUG G3/8X13                   1
36       90164800       OIL SEAL 30x55x7               1
35       47151322       SIDE CRANKCASE COVER (ATEX) 1


35       47151022       OPEN SIDE COVER (47-66)        1
34       66219566       PISTON BOLT                    3
33       90358400       O-RING D.10,82X1,78(2043)90SH 3


32       66040009       PISTON D. 20X54                3
31       96710100       WASHER D. 10X28X0.5            3
30       66050066       PISTON GUIDE - S.S.            3
29       97740500       CONNECTING ROD-PIN D.14X39 3


28       99309900       SCREW M 8x35 UNI 5931          6
27       90358500       O-RING 10,82X1,78 (2043)       4
26       98203600       PLUG G1/4x8 FOR PROBE D.6      1
                        S.S.




W3025                                                              3/21/2026   Page 10 - 11
Copyright INTERPUMP GROUP S.P.A
Illustration Male shaft (key) - vers. ATEX

Pos.   Code             Description                   Qty Notes

25     99188400         SCREW M 6x20 UNI 5931         4
24     66160022         REAR COVER                    1
23     90392200         O-RING D.133.02X 2,62(3525)   1


22     66030001         CONNECTING ROD                3
21     91489200         KEY 8(h9)X7X35 UNI 6604/A     1


20     66020035         CRANKSHAFT C.19 - D. 24       1
19     98210700         OIL DIPSTICK G3/8X64          1
                        D4+FILTER ATEX
18     66010022         CRANKCASE                     1
17     91838000         ROLLER BEARING NJ2206EC       2
16     90075500         STOP RING J45 UNI7437         1
15     70211751                                       1
14     90387700         O-RING 39,34X2,62 (3156)      1
13     90391300         O-RING 67,95X2,62 (3268)      2
11     99303900         SCREW M 8x16 UNI 5931         8
10     36712701         INTAKE/DEL.VALVE ASSY(66)     6


9      66130041         VALVE CAP M32x1.5x29.5        6
8      90516500         ANTI-EXTR.RING D.24.7x29x1.5 6


7      36203551         VALVE CAGE                    6
6      94738800         SPRING Dm. 10x18.5            6
5      36203476         SPHERICAL VALVE               6
4      36203366         VALVE SEAT                    6
3      90385700         O-RING 23,81X2,62 (132)       12
2      99380100         SCREW M10X90 UNI 5931 8.8     8


1      66120041         PUMP HEAD (PISTON D.20)       1




W3025…

Technical Documents

(1)

Technical Data Sheet

PDF Document

Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.

Talk to an engineer

Ask a question

Pratissoli Products

3G Electric (S) Pte. Ltd. — Singapore

Product Description

Frequently Asked Questions

Where can I buy the Pratissoli SN71106 R pump worldwide?

3G Electric is an authorized Pratissoli distributor. We source the SN71106 R pump and handle all logistics, customs clearance, and delivery globally. Contact us for availability and lead times on this 40.4 kW, 106 L/min unit.

What is the lead time for the Pratissoli SN71106 R?

Lead time varies based on current sourcing conditions. The Pratissoli SN71106 R (40.4 kW, 106 L/min at 200 bar) is available to order. Contact 3G Electric with your required delivery date for a specific quote and timeline.

What flow rate and pressure does the Pratissoli SN71106 R deliver?

The Pratissoli SN71106 R operates at 1000 rpm, delivering 106 L/min (28 US gpm) at 200 bar (20 MPa / 2900 psi). It develops 40.4 kW output and weighs 68 kg, making it suitable for high-pressure industrial hydraulic systems.

Used in

Common applications for Pratissoli

High-pressure industrial cleaning systems — Pratissoli SN7070F and SN71106F pumps (130–200 bar) for sustained pump duty in fixed or mobile wash equipment

Marine and shipboard hydraulic systems — SS7061H and SS71153 pumps rated 150–160 bar for deck machinery and propulsion auxiliaries requiring compact, reliable units

Construction equipment hydraulics — SN7193 and SN71106 models (200–210 bar) for excavator, loader, and crane power-transmission circuits

Industrial press and forming machinery — Pratissoli pump assemblies with ZR1X regulating valves (400 bar) for closed-loop pressure control in metal-working and rubber-molding lines

Mining and aggregates processing — Long-duty SS and SN series pumps (130–160 bar) supplying conveyor drives, screen shakers, and mobile crusher circuits

Oil and gas transfer and metering — Pratissoli regulating-valve models (H168A, R1/200) in skid-mounted pump packages for fluid loading, injection, and line-pressure stabilization

Spare Parts & Repair Kits

Official SN71106 parts list — 70 parts, 16 available in catalog

Official Parts List

SN71106 — Male shaft (key) - GAS exploded diagram

Individual Components

PosCodeDescriptionQty

SHIM 0.25 MM.

70220381×1Available

Pratissoli PUMP SN71106 R

Local availability & support

Technical Specifications

Datasheet Content

Technical Documents

Need installation or engineering help?

Ask a question

Product Description

Frequently Asked Questions

Used in

Spare Parts & Repair Kits

Recommended Spare Parts

Pratissoli Products

You might also need
