PUMP E1C1609 R

Name: PUMP E1C1609 R
Brand: Interpump
SKU: pump-e1c1609-r

On RequestIndustrial Pumps

Price on request — send us an enquiry for current pricing.

PUMP E1C1609 R

Minimum order: 4 units
Lead time: Worldwide DHL shipping from Singapore; 7–14 business days door-to-door for most destinations.

Technical specifications

power hp	3.7
power kw	2.72
weight kg	5
flow l min	9
flow us gpm	2.38
pressure bar	160
pressure mpa	16
pressure psi	2320
rotation regime rpm	1750
overall dimensions l x l x h mm	194.5

Frequently asked questions

Where can I buy the Interpump E1C1609 R pump worldwide?+

3G Electric is an authorized Interpump distributor supplying the E1C1609 R globally. We handle sourcing, logistics, and customs clearance. Lead time on request — contact us for availability and delivery terms.

What are the power and flow specifications of the E1C1609 R?+

The Interpump E1C1609 R delivers 9 L/min (2.38 US gpm) at 160 bar (16 MPa, 2320 psi). Power input is 2.72 kW (3.7 hp) at 1750 rpm operating speed. Weight is 5 kg, making it suitable for compact hydraulic systems.

Is the E1C1609 R suitable for high-pressure hydraulic applications?+

Yes. The E1C1609 R is a gear pump rated for 160 bar continuous operation at 1750 rpm, delivering consistent 9 L/min flow. Its compact 5 kg design suits space-constrained high-pressure hydraulic circuits requiring reliable industrial performance.
