OMRON Solid State Relay: Surface Mounted, 10 A Max Output Current, Photocoupler - Surface-Mounted Relays
OMRONSurface-Mounted Relays

OMRON Solid State Relay: Surface Mounted, 10 A Max Output Current, Photocoupler

The OMRON Solid State Relay: Surface Mounted (SKU 1YDL5, MPN G3NA-610B-DC5-24) is a surface-mounted relay with a DC input current range of 0.6 to 15 A and an AC output voltage of 400 to 600V AC. It features a Form A…

SKU 3G-OTH-40284

Brand
OMRON
Item
Solid State Relay: Surface Mounted, 10 A Max Output Current, Photocoupler
Category
Surface-Mounted Relays
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

OMRON
Manufacturer Part Number
G3NA-610B-DC5-24
Type
Photocoupler, AC Output
Finger Safe
Yes
Current Type
DC
Input Current
0.6 to 15 A
Mounting Style
Surface
Output Voltage
400 to 600V AC
Max Output Current
10 A
Switch Configuration
Form A
Voltage/Current Type
AC Output
Electrical Connection
Screw Clamp
Maximum Output Current without Heat Sink
4 A
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

OMRON Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The OMRON Solid State Relay: Surface Mounted (SKU 1YDL5, MPN G3NA-610B-DC5-24) is a surface-mounted relay with a DC input current range of 0.6 to 15 A and an AC output voltage of 400 to 600V AC. It features a Form A switch configuration, a screw clamp electrical connection, and is finger safe. The maximum output current without a heat sink is 4 A.
