EATON Lighted Rocker Switch: 2 Positions, SPDT, On/On - General Purpose Rocker Switches
EATONGeneral Purpose Rocker Switches

EATON Lighted Rocker Switch: 2 Positions, SPDT, On/On

The EATON XR1CG44NV1XX is a general purpose lighted rocker switch from the Series X line, featuring a 2-position, SPDT, On/On configuration with amber illumination. It is rated for 10 A at 277 V AC and 3/4 hp at 277…

SKU 3G-OTH-35219

Brand
EATON
Item
Lighted Rocker Switch: 2 Positions, SPDT, On/On
Category
General Purpose Rocker Switches
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

EATON
Manufacturer Part Number
XR1CG44NV1XX
Series
X
Horsepower
3/4 hp @ 277 V
Includes Lens
Lens Included
Displayed Brand
EATON
AC Contact Rating
10 A @ 277 V
Operator Illumination
Illuminated
Terminal Connection Type
0.25 in Quick Connect Tab
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

EATON Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The EATON XR1CG44NV1XX is a general purpose lighted rocker switch from the Series X line, featuring a 2-position, SPDT, On/On configuration with amber illumination. It is rated for 10 A at 277 V AC and 3/4 hp at 277 V, with a 0.25 in quick connect tab terminal connection and an included lens.
