TF 834.3 relay

Name: TF 834.3 relay
Brand: Satronic
SKU: cbm-rel20105-tf-834-3-relay-rel-relays-and-cells-1

On RequestBurner Controls

Price on request — send us an enquiry for current pricing.

TF 834.3 relay

Minimum order: 5 units
Lead time: Worldwide DHL shipping from Singapore; 7–14 business days door-to-door for most destinations.

Technical specifications

operation	Intermittent
application	Automatic control for oil burners
safety time	10 sec
flame detector	MZ 770 S photoresistor
burner capacity	30 kg/h
preheating time	12 sec
detector current	30 µA
mounting position	Any
protection rating	IP 44
ambient temperature	0°C to 60°C
postignition time TF834	20 sec

Frequently asked questions

Where can I buy the Satronic TF 834.3 relay in your region?+

3G Electric supplies the Satronic TF 834.3 relay for immediate quotation and order. We deliver to your location with full customs import and customs handling included. Contact us for lead times and USD pricing.

What is the lead time for the Satronic TF 834.3 relay to your region?+

Lead times are available on request. 3G Electric sources this relay and arranges delivery to your location, managing all logistics and documentation. Quotation turnaround is 24–48 hours.

What burner capacity does the Satronic TF 834.3 handle?+

The TF 834.3 is rated for automatic control of oil burners up to 30 kg/h capacity. Safety time is 10 sec, preheating interval is 12 sec, and post-ignition time is 20 sec. IP 44 protection suits industrial combustion systems in 0°C to 60°C ambient.
