CBMHVAC & Refrigeration

CBM Vibration damper 1/2"

SKU 3G-CBM-01744

Also listed as: CRE 14006 · CRE-14006

Brand

CBM

Item

Vibration damper 1/2"

Local availability & support

Delivery: Worldwide DHL shipping from Singapore; 7–14 business days door-to-door for most destinations.
Payment: Invoicing in USD. Bank transfer (SWIFT) and corporate PO accepted.

Technical Specifications

CBM

hose material

Stainless steel

peak pressure

2500 psiG

tube material

Copper (Cu-DHP) or solderable terminal in stainless steel

dimension b mm

12.8 mm (±3)

dimension c mm

20 mm (±3)

dimension d mm

188.6 mm (±6)

dimension y mm

228.6 mm (±1.5)

welding method

Automatic argon arc welding

connection size

1/2 inch

working pressure

500 psiG

braiding material

Stainless steel

internal weld ends

Both copper tube ends (internal welding to prevent external leakage)

protective sleeves

Yes, to protect hose clamp on extended copper tubes and reduce cross-section during argon arc welding

inner diameter id mm

12.8 mm

external ring material

Stainless steel

straight tube material

Stainless steel

Datasheet Content

Mode d'emploi

         CONCEPT




AMORTISSEURS DE VIBRATIONS




CRE14004-24
     Cuivre (Cu-DHP)             Tube droit en
     ou borne à souder           acier inoxydable
     en acier inoxydable

                                                                                                         Anneau externe en
                                                                                                         acier inoxydable
                                               Tressage en acier inoxydable
     Tuyau en acier inoxydable


     SPÉCIFICATIONS TECHNIQUES
       1. Ajustement de la structure : tube en cuivre prolongé à partir des deux extrémités du
          tuyau ondulé.
       2. Les manchons protègent le collier de serrage sur les tubes en cuivre prolongés et
          réduisent la surface transversale pendant le processus de soudage à l'arc sous
          argon.
       3. Utilisez une machine à souder à l'arc sous argon automatique pour éviter les défauts
          causés par les opérations de soudage manuel.
       4. Utilisez un soudage interne pour les deux extrémités des tubes en cuivre afin d'éviter
          les points de fuite causés par le soudage externe normal.




                                                                         Dimensions
                                                                                                                  Pression Pression
     Référence        Description                              B             C            D            Y         de service de pointe
                                                (I.D.)                                                              max        max
                                                              (±3)          (±3)         (±6)        (±1.5)
                                             1 millimètre
                                                            millimètre    millimètre   millimètre   millimètre     (psiG)     (psiG)

     CRE14004 Amortisseur vibrations 3/8        9.62           20           177.5       217.5          13           500       2500
     3G-CBM-01744 Amortisseur vibrations 1/2        12.8           20           188.6       228.6          13           500       2500
     CRE14008 Amortisseur vibrations 5/8        16.2           22           206.8       250.8          17           500       2500
     CRE14010 Amortisseur vibrations 3/4       19.2            28           212.3       268.3          17           500       2500
     CRE14012 Amortisseur vibrations 7/8       22.5            30           244.8       304.8         18            500       2500
     CRE14014 Amortisseur vibrations 1-1/8     28.8            38           255.3       331.3          20           500       2500
     CRE14016 Amortisseur vibrations 1-3/8     35.3            40           315.0       395.0         22            500       2500
     CRE14018 Amortisseur vibrations 1-5/8      41.7           50           328.6       428.6          23           500       2500

     CRE14020 Amortisseur vibrations 2-1/8     54.5            60           403.8       523.8          23           390       1950
     CRE14022 Amortisseur vibrations 2-5/8     67.0            76           465.5       617.5          25           340       1700
     CRE14024 Amortisseur vibrations 3-1/8      79.6           85           514.2       684.2          25           300       1500




02

Technical Documents

(1)

Technical Document 1

PDF Document

Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.

Talk to an engineer

Ask a question

CBM Products

3G Electric (S) Pte. Ltd. — Singapore

Product Description

The CBM Vibration damper 1/2" is a refrigeration component with a 1/2-inch connection size, designed for a working pressure of 500 psiG and a peak pressure of 2500 psiG. It features stainless steel hose and braiding, copper (Cu-DHP) or solderable stainless steel tube ends, and automatic argon arc welding with internal weld ends to prevent external leakage. Protective sleeves are included to safeguard the hose clamp on extended copper tubes during welding.

Frequently Asked Questions

Where can I buy the CBM CRE14006 vibration damper worldwide?

3G Electric is an authorized CBM distributor. We source the CRE14006 vibration damper 1/2" for worldwide delivery. Lead time on request — contact us for availability and logistics coordination.

What is the working pressure rating of the CBM CRE14006?

The CBM CRE14006 operates at 500 psiG working pressure with a peak pressure rating of 2500 psiG. The hose is stainless steel with a copper (Cu-DHP) tube for refrigeration applications.

What materials are used in the CBM CRE14006 damper construction?

The CRE14006 features stainless steel braiding, copper (Cu-DHP) or solderable stainless steel tube, and automatic argon arc welding. Connection size is 1/2 inch with dimensions: 228.6 mm (Y) × 188.6 mm (D) overall length.
