Allanson AHVPS-714-40-MV High Voltage Power Supply
Our High Voltage Power Supplies convert the 120/240VAC volt, 60 HZ single phase AC supply into the high voltage DC required to power ionizing collection cells. Potential of 14KVDC is required for the Ionizer section…
SKU 3G-OTH-02988
Also listed as: AHVPS71440MV · AHVPS 714 40 MV
Local availability & support
- Delivery
- Worldwide DHL shipping from Singapore; 7–14 business days door-to-door for most destinations.
- Payment
- Invoicing in USD. Bank transfer (SWIFT) and corporate PO accepted.
Need installation or engineering help?
Ask a question
Product Description
Our High Voltage Power Supplies convert the 120/240VAC volt, 60 HZ single phase AC supply into the high voltage DC required to power ionizing collection cells. Potential of 14KVDC is required for the Ionizer section and 7KVDC for the collector section of the cells.
Frequently Asked Questions
What is the Allanson 3G-OTH-02988 used for?
The Allanson 3G-OTH-02988 is a high voltage power supply designed for electrostatic air cleaners. It converts 120V-240V AC input into 14KVDC for the ionizer section and 7KVDC for the collector section, powering the ionizing collection cells to remove airborne particles.
What are the specifications of the Allanson 3G-OTH-02988?
The Allanson 3G-OTH-02988 has dimensions of 12"x15"x6", input voltage 120V-240V, max output current 40mA, max output power 500W, and max output voltage 14/7KVDC for ionizer/collector. It features a Nema 4 enclosure and draws 4A at 120V or 2A at 240V.
Where to buy the Allanson 3G-OTH-02988 in Singapore?
You can source the Allanson 3G-OTH-02988 through 3G Electric in Singapore. We provide logistics, customs clearance, and delivery services to your facility. Contact us for pricing and lead time on this high voltage power supply.
How to install the Allanson 3G-OTH-02988?
Install the Allanson 3G-OTH-02988 indoors in a NEMA 1 rated enclosure, protected from weather. Use pre-punched knockouts for conduit attachment. Connect AC line to J3, ensure proper wire gauge per local codes, and do not modify the enclosure to maintain safety and warranty.
